AS-1115CS-TNR | Supermicro Single Socket Epyc 9004 1U Server
Başlayan €2.849,50*
KDV artı nakliye masrafları dahil fiyatlar
Supermicro AS-1115CS-TNR
Unleash the Power of Performance with the Supermicro AS-1115CS-TNR
Introducing the AS-1115CS-TNR, an exceptional barebone system crafted by the renowned experts at Supermicro. Designed for those who demand efficiency and reliability, this powerhouse provides the perfect foundation for your next high-performance computing project. The AS-1115CS-TNR is engineered to elevate your computing setup with its robust construction and advanced capabilities. Whether you're a tech enthusiast, IT professional, or a business looking to maximize resources, this barebone system promises top-tier performance to meet your needs.
Why Choose the Supermicro's AS-1115CS-TNR?
Supermicro's reputation for quality and innovation ensures that the AS-1115CS-TNR stands out in the market. This system is an embodiment of unparalleled engineering and meticulous attention to detail, providing the reliability and efficiency your projects deserve.
This cloud-optimised server is engineered to support cutting-edge technologies, enabling businesses to push their operations to the next level. Its dual PCIe 5.0 x16 slots ensure blazing-fast data transfer speeds, making it ideal for high-performance applications and virtualisation. With the ability to support 10 hot-swap 2.5" NVMe/SAS/SATA bays, data storage is simple and flexible, while the M.2 PCIe 3.0 x2 NVMe slots add another layer of expansion. Perfect for industries relying on high availability and high-demand applications, the Supermicro AS-1115CS-TNR provides not only performance but also the reliability that businesses depend on. Whether you’re in need of a powerful server for cloud computing, AI applications, or data-driven workloads, this unit guarantees you the performance edge.
Key Applications:
• Web Server, Firewall Application
• Data Center Optimized, Value IaaS
• Cloud Computing, Compact Server
• DNS & Gateway Servers, Firewall Application
• CDN, Edge Nodes
Ready to explore more about what Supermicro's AS-1115CS-TNR can offer? Contact us at Happyware now to discuss how the AS-1115CS-TNR can transform your business operations. Call us today to get started and explore the full potential of this cutting-edge server solution!
Supermicro AS-1115CS-TNR Teknik Özellikleri
| Single AMD EPYC 9004 CPU, 10x 2.5" hot-swap drive bays, 4x PCIe Gen5 (2x FHHL, 2x AIOM), Networking via Slim-AIOM, 2x 860W redundant PSUs |
| Processor | |
|---|---|
| CPU | Single Socket SP5 4th Generation AMD EPYC™ 9004 Series Processor Support CPU TDP up to 360W * |
| Cores | Up to 96C/192T |
| Note | *Certain CPUs with high TDP may be supported only under specific conditions. |
| System Memory | |
|---|---|
| Memory Capacity | 12 DIMM slots Up to 3TB: 3DS ECC Registered RDIMM, DDR5-4800MHz |
| Memory Type | 4800MHz ECC DDR5 RDIMM (3DS) Up to 256GB of memory |
| Memory Voltage | 1.1 V |
| Error Detection | Corrects single-bit errors Detects double-bit errors (using ECC memory) |
| On-Board Devices | |
|---|---|
| Chipset | System on Chip |
| Network Connectivity | Via Slim-AIOM |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
| Input/Output | |
|---|---|
| LAN | 1 Dedicated IPMI LAN port |
| USB | 2 USB 2.0 ports (2 front) 2 USB 3.0 ports (2 rear) |
| Video | 1 VGA port |
| Serial Port | 1 COM Port (1 rear) |
| System BIOS | |
|---|---|
| BIOS Type | AMI 32MB SPI Flash ROM |
| BIOS Features | ACPI 6.4 Plug and Play (PnP) SMBIOS 3.5 or later UEFI 2.8 USB Keyboard support |
| Management | |
|---|---|
| Software | IPMIView for Linux/ Windows IPMICFG SSM SPM SUM Watch Dog SuperDoctor® 5 |
| Power Configurations | Power-on mode control for AC power loss recovery ACPI Power Management |
| PC Health Monitoring | |
|---|---|
| Voltage | System temperature, Memory temperature, CPU temperature, 3.3V standby, +5V standby, +5V, +3.3V, +12V, CPU thermal trip support |
| Fan | Fans with tachometer monitoring Pulse Width Modulated (PWM) fan connectors Status monitor for speed control |
| Temperature | Monitoring for CPU and chassis environment Thermal Control for fan connectors |
| Chassis | |
|---|---|
| Form Factor | 1U Rackmount |
| Model | CSE-LB16TS-R860AWP-A |
| Dimensions and Weight | |
|---|---|
| Height | 4.31cm (43mm) |
| Width | 43.68cm (437mm) |
| Depth | 59.69cm (597mm) |
| Package | 19.81cm (H) x 60.45cm (W) x 82.29cm (D) |
| Weight | Net Weight: 25 lbs (11.3 kg) Gross Weight: 46 lbs (20.9 kg) |
| Available Color | Black front & Silver body |
| Front Panel | |
|---|---|
| Buttons | Power On/Off button UID button |
| LEDs | Drive activity Network activity Power status Universal Information (UID) |
| Expansion Slots | |
|---|---|
| PCI-Express | 2 PCIe 5.0 x16 FHHL slots 2 PCIe 5.0 x16 AIOM slot |
| Note | Acronyms: (FH = Full Height, LP = Low Profile, FL = Full Length, HL = Half Length) |
| Storage | |
|---|---|
| Drive Bays | 10x 2.5" hot-swap NVMe/SATA/SAS drive bays (10x 2.5" NVMe hybrid) (10x 2.5" SATA by default) |
| M.2 | 2x NVMe (PCIe Gen 3x2, Boot drive only) M-Key, 2280/22110 |
| System Cooling | |
|---|---|
| Fans | 6x 4cm heavy duty fans with optimal fan speed control |
| Air Shroud | 1 Air Shroud |
| Power Supply | |
|---|---|
| 800W/860W 1U redundant power supply | |
| Dimension (W x H x L) | 54.5 x 40.25 x 322 mm |
| AC Input | 800W: 100-127Vac / 9A-7.5A / 50-60Hz 860W: 200-240Vac / 6A-4.5A / 50-60Hz |
| +12V | Max: 66.6A / Min: 0A (100Vac-127Vac) Max: 71.6A / Min: 0A (200Vac-240Vac) |
| 5V SB | Max: 4A / Min: 0A |
| Output Type | Backplanes (gold finger) |
| Certification | 80 PLUS 94% Platinum Level |
| Operating Environment | |
|---|---|
| Environmental Spec. | Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Order Information | ||
|---|---|---|
| Manufacturer SKU | AS-1115CS-TNR | |
| System Building | AS-1115CS-TNR configured by Supermicro as Complete System | |
Supermicro AS-1115CS-TNR Nitelikleri
| Add-on card form factor: | FH, HH, OCP 3.0 |
|---|---|
| Applications: | Big Data, CDN, Cloud Computing, Compact Server, DNS & Gateway Servers, Data Center Applications, Data Center Optimized, Database, Edge/Cloud Computing Services, Edge Nodes, Firewall Application, Web/Hosting Application, Web Server |
| Backplane: | Yes |
| Backplane Interface: | SAS 1.0, SAS 2.0, SAS 3.0, SATA I, SATA II, SATA III, U.2 NVMe |
| Bluetooth Support: | None |
| CPU Codename: | Genoa |
| CPU Manufacturer: | AMD |
| CPU Socket: | SP5 |
| Card Reader Support: | No |
| Certification: | 80 Plus Platinum |
| Chassis Intrusion: | No |
| Computer group: | Server |
| Design: | Rackmount |
| Front I/O: | LED Indicators, USB Type-A |
| GPU quantity per node: | 2 |
| Height units: | 1U |
| HotSwap/Fixed Drives: | Yes |
| HotSwap/Fixed Power Supply: | Hot-Swap Power Supply |
| IPMI / BMC: | Yes |
| Lighting: | LED |
| Motherboard Chipset: | SP5 |
| Number of CPU sockets: | No |
| Number of RAM Pins: | 288 |
| Number of RAM Slots: | N/A |
| Onboard Graphic: | No |
| Onboard LAN: | No |
| Onboard Network Speed: | 1 Gb/s |
| PSU Power Wattage: | 860W |
| Performance Class: | Enterprise-Class, High-End |
| Power Supply Cooler: | No |
| Pre-installed Components: | None |
| Pre-installed Software: | Citrix Hypervisor (formerly XenServer), Oracle Linux, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi |
| Product Model: | 1115CS-TNR |
| Quantity of Cooler: | 6 |
| Quantity of Power Supplies: | 2 |
| RAID Support: | No |
| RAM DIMM Type: | RDIMM |
| RAM ECC: | ECC |
| RAM registered/unregistered: | Registered |
| Redundant power: | Yes |
| Server Fanless: | No |
| Special Features: | LEDs |
| Specific Ports: | M.2 Ports, NVMe Ports, SAS Ports, SATA Ports, U.2 Ports, USB Ports, VGA Ports |
| Suitability: | Server |
| Use case: | Cloud Computing, Database Server, Edge Server, Firewall, Web Hosting |
| Wi-Fi Support: | None |
| iGPU Manufacturer: | N/A |
