AS-2115GT-HNTR | Supermicro Single Socket Epyc 9004 2U Server
Başlayan €9.862,89*
KDV artı nakliye masrafları dahil fiyatlar
Supermicro AS-2115GT-HNTR
Experience Unmatched Performance with the Supermicro AS-2115GT-HNTR Barebone System
Introducing the cutting-edge AS-2115GT-HNTR from Supermicro, a leader in high-performance computing solutions. This barebone system is meticulously engineered to meet the demands of modern computing environments, offering robust and reliable performance for both business and personal use.
Why Choose the AS-2115GT-HNTR?
The AS-2115GT-HNTR provides a versatile foundation for building a customized server that can handle heavy workloads with ease. Whether you're running complex applications, virtualizations, or data-intensive tasks, this system is designed to deliver seamless operation and maximum efficiency.
With the trusted quality and innovation of Supermicro, the AS-2115GT-HNTR ensures long-lasting durability and superior thermal design, keeping your components cool and performing at their best even under pressure. Its modular design allows for convenient upgrades and expansions, giving you the flexibility to meet ever-evolving technology needs.
Key Applications:
• High-performance Computing
• MEC (Multi-Access Edge Computing), Multi-Purpose CDN
• Telco Edge Cloud, High-availability Cache Cluster
• Mission Critical Web Applications
• Cloud Gaming
• EDA (Electric Design Automation)
Contact us at Happyware today to discuss how the Supermicro AS-2115GT-HNTR can revolutionise your computing capabilities. Call us now to get started, or register your company as a partner with Happyware to unlock exclusive benefits and superior support. Don’t miss the opportunity to elevate your infrastructure with this cutting-edge server solution!
Supermicro AS-2115GT-HNTR Teknik Özellikleri
| Single AMD EPYC 9004 Series CPU, 6x 2.5" hot-swap drive bays, 2x PCIe (AIOM), 2x 2200W redundant PSUs |
| Processor / Chipset (per Node) | |
|---|---|
| CPU | Single Socket SP5 AMD EPYC™ 9004 Series Processors |
| Core Count | Up to 128C/256T |
| Note | Supports up to 290W TDP CPUs (Air Cooled) |
| System Memory (per Node) | |
|---|---|
| Memory | Slot Count: 12 DIMM slots Max Memory (1DPC): Up to 3TB 4800MT/s ECC DDR5 RDIMM |
| On-Board Devices (per Node) | |
|---|---|
| Chipset | AMD SP5 |
| Network Connectivity | Via IO Module |
| Input / Output (per Node) | |
|---|---|
| LAN | 1 RJ45 1 GbE Dedicated BMC LAN port |
| USB | 2 USB 3.0 ports |
| Video | 1 VGA port |
| System BIOS (per Node) | |
|---|---|
| BIOS Type | AMI 32MB Flash ROM |
| Management | |
|---|---|
| Software | SuperCloud Composer Supermicro Server Manager (SSM) Supermicro Update Manager (SUM) Supermicro SuperDoctor® 5 (SD5) Super Diagnostics Offline (SDO) Supermicro Thin-Agent Service (TAS) SuperServer Automation Assistant (SAA) New! |
| Security | |
|---|---|
| Hardware | Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Features | Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery Supply Chain Security: Remote Attestation Runtime BMC Protections System Lockdown |
| PC Health Monitoring | |
|---|---|
| FAN | Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors |
| Temperature | Monitoring for CPU and chassis environment |
| Voltage | Voltage, VBAT, Memory temperature, CPU temperature, 3.3V standby, +5V standby, +5V, +3.3V, +12V, VRM temperature, CPU thermal trip support, 1.8V standby |
| Chassis | |
|---|---|
| Form Factor | 2U Rackmount |
| Model | CSE-GT214BC-R2K21BP |
| Dimensions | |
|---|---|
| Height | 8.8cm (88mm) |
| Width | 44.88cm (449 mm) |
| Depth | 71.12cm (711.2 mm) |
| Package | 24.79cm (H) x 62.61cm (W) x 115.01cm (D) |
| Weight | Gross Weight: 88 lbs (39.9 kg) Net Weight: 68 lbs (30.8 kg) |
| Available Colors | Silver |
| Front Panel | |
|---|---|
| LED | HDD activity LED Network activity LEDs Power status LED Universal Information (UID) LED |
| Buttons | Power On/Off button UID button |
| Expansion Slots (per Node) | |
|---|---|
| PCI-Express | Default 2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible) |
| Storage (per Node) | |
|---|---|
| Drive Bays | Default: Total 6 bays 6 front hot-swap 2.5" NVMe/SATA drive bays |
| M.2 | 2 M.2 NVMe/SATA slots (M-key) |
| System Cooling | |
|---|---|
| Fans | 2x 17.6K RPM Heavy Duty 8cm Fans |
| Air Shroud | 1 per node Air Shroud |
| Power Supply | |
|---|---|
| 2x 2200W Redundant Titanium Level (96%) power supply | |
| Dimension (W x H x L) | 106.5 x 84 x 245.3 mm |
| AC Input | 100-127Vdc (1200W for the Rest of the World) 1200W: 100-127Vac / 50-60Hz 2090W: 180-220Vac / 50-60Hz (For UL/cUL Only) 200-220Vdc (1800W for the Rest of the World) 200-220Vdc (2090W for North America - UL & cUL) 1800W: 200-220Vac / 50-60Hz 220-230Vdc (1980W for the Rest of the World) 1980W: 220-230Vac / 50-60Hz 220-240Vdc (2200W for North America - UL & cUL) 2200W: 220-240Vac / 50-60Hz (For UL/cUL Only) 230-240Vdc (2090W for the Rest of the World) 2090W: 230-240Vdc / 50-60Hz (for CQC only) 2090W: 230-240Vac / 50-60Hz (for TUV/CB) |
| +12V | Max: 100A / Min: 0A (100Vac-127Vac) Max: 174.17A / Min: 0A (180Vdc-220Vdc) (For UL/cUL only) Max: 174.17A / Min: 0A (180Vac-220Vac) (For UL/cUL Only) Max: 150A / Min: 0A (200Vac-220Vac) Max: 165A / Min: 0A (220Vac-230Vac) Max: 183.3A / Min: 0A (220Vac-240Vac) Max: 183.3A / Min: 0A (220Vac-240Vac) (For UL/cUL only) Max: 174.17A (230Vac-240Vac) |
| 12V SB | Max: 2A / Min: 0A |
| Output Type | Backplanes (gold finger) |
| Certification | Titanium Level |
| Operating Environment | ||
|---|---|---|
| RoHS | RoHS Compliant | |
| Environmental Spec. | Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -30°C to 60°C (-22°F to 140°F) Operating Relative Humidity: 8% to 80% (non-condensing) Non-operating Relative Humidity: 8% to 90% (non-condensing) | |
| Order Information | ||
|---|---|---|
| Manufacturer SKU | AS-2115GT-HNTR | |
| System Building | AS-2115GT-HNTR configured by Supermicro as Complete System | |
Supermicro AS-2115GT-HNTR Nitelikleri
| Add-on card form factor: | OCP 3.0 |
|---|---|
| Applications: | 5G/Telco, CDN, Cloud Computing, Edge/Cloud Computing Services, Edge Nodes, HPC, Mission Critical, Web/Hosting Application, Web Server |
| Backplane: | Yes |
| Backplane Interface: | SATA I, SATA II, SATA III, U.2 NVMe |
| Bluetooth Support: | None |
| CPU Codename: | Genoa |
| CPU Manufacturer: | AMD |
| CPU Socket: | SP5 |
| Card Reader Support: | No |
| Certification: | 80 Plus Titanium |
| Chassis Intrusion: | No |
| Computer group: | Server |
| Design: | Rackmount |
| Front I/O: | LED Indicators |
| Height units: | 2U |
| HotSwap/Fixed Drives: | Yes |
| HotSwap/Fixed Power Supply: | Hot-Swap Power Supply |
| IPMI / BMC: | Yes |
| Lighting: | LED |
| Motherboard Chipset: | SP5 |
| Number of CPU sockets: | No |
| Number of RAM Pins: | 288 |
| Number of RAM Slots: | N/A |
| Onboard Graphic: | No |
| Onboard LAN: | No |
| Onboard Network Speed: | 1 Gb/s |
| PSU Power Wattage: | 2200W |
| Performance Class: | Enterprise-Class, High-End |
| Power Supply Cooler: | No |
| Pre-installed Components: | None |
| Pre-installed Software: | Windows Server |
| Product Model: | 2115GT-HNTR |
| Quantity of Cooler: | 2 |
| Quantity of Power Supplies: | 2 |
| RAID Support: | No |
| RAM DIMM Type: | RDIMM |
| RAM ECC: | ECC |
| RAM registered/unregistered: | Registered |
| Redundant power: | Yes |
| Server Fanless: | No |
| Special Features: | LEDs |
| Specific Ports: | M.2 Ports, NVMe Ports, SATA Ports, U.2 Ports, USB Ports, VGA Ports |
| Suitability: | Server |
| Use case: | Cloud Computing, Cluster Node, Edge Server, High-Performance Computing (HPC), Web Hosting |
| Wi-Fi Support: | None |
| iGPU Manufacturer: | N/A |
