Supermicro SYS-211GT-HNTR
Exceptional Scalability with the Supermicro SYS-211GT-HNTR GrandTwin SuperServer Barebone System
Introducing the cutting-edge SYS-211GT-HNTR from the renowned manufacturer, Supermicro. This Barebone system is designed to propel your business into the future with unmatched performance and reliability. The Supermicro SYS-211GT-HNTR GrandTwin SuperServer offers groundbreaking flexibility in a 2U form factor with four hot-pluggable nodes, each capable of supporting up to 6 hot-swap 2.5" NVMe/SATA drives. Designed for high-density, high-performance applications, each node is powered by Intel® Xeon® Scalable processors (5th/4th Gen) and supports up to 4TB of DDR5 memory, providing enterprises with the computational power and storage capacity required for demanding environments. The shared cooling design and redundant 2200W power supplies ensure stable operation, even under heavy workloads.
Why Choose the Supermicro SYS-211GT-HNTR?
The SYS-211GT-HNTR is your gateway to advanced computing solutions, offering a blend of powerful processing capabilities and seamless integration options. Whether you're looking to enhance your data center, optimize your computing operations, or explore new heights of technological innovation, this system is engineered to meet your most demanding requirements.
The SYS-211GT-HNTR is the perfect solution for businesses seeking to maximize performance without sacrificing space. Featuring four independent nodes, this GrandTwin SuperServer optimizes space efficiency, allowing for a high degree of parallelism while maintaining peak performance across all units. Each node benefits from the advanced Intel® Xeon® processors and extensive memory support, ensuring high computing throughput for mission-critical tasks. The system’s shared power and cooling infrastructure enhances efficiency while reducing operational complexity, making it an ideal choice for scalable enterprise applications.
Key Applications:
• HPC
• Cloud Gaming
• MEC (Multi-Access Edge Computing)
• Multi-Purpose CDN
• High-availability Cache Cluster
• Telco Edge Cloud
• EDA (Electric Design Automation)
• Mission Critical Web Applications
Invest in the future with the SYS-211GT-HNTR and experience the ultimate in computing excellence. Contact Happyware today and unlock the power of the Supermicro SYS-211GT-HNTR for your infrastructure.
Supermicro SYS-211GT-HNTR Teknik Özellikleri
| Single Intel Xeon Scalable 5th Gen CPU, 6x 2.5" hot-swap drive bays, 2x PCIe (LP), 1x 1GbE LAN, 2x 2200W redundant PSUs |
| Processor/Cache (per Node) | |
|---|---|
| CPU | Single Socket E (LGA-4677) 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors |
| Cores | Up to 64C/128T; Up to 300MB Cache |
| Note | *Supports up to 350W TDP CPUs (Air Cooled)* *Air Cooled CPUs with TDP over 350W only supported under specific conditions. |
| System Memory (per Node) | |
|---|---|
| Memory | Slot Count: 16 DIMM slots/2 Channels Max Memory (2DPC): Up to 4TB 5600MT/s ECC DDR5 RDIMM |
| On-Board Devices (per Node) | |
|---|---|
| Chipset | Intel® C741 |
| Network Connectivity | Via IO Module |
| Input / Output (per Node) | |
|---|---|
| LAN | 1 RJ45 1 GbE Dedicated BMC LAN port |
| USB | 2 USB 3.0 ports |
| Video | 1 VGA port |
| System BIOS | |
|---|---|
| BIOS Type | AMI 32MB Flash ROM |
| Management | |
|---|---|
| Software | SuperCloud Composer Supermicro Server Manager (SSM) Supermicro Update Manager (SUM) Supermicro SuperDoctor® 5 (SD5) Super Diagnostics Offline (SDO) Supermicro Thin-Agent Service (TAS) SuperServer Automation Assistant (SAA) New! |
| Security | |
|---|---|
| Hardware | Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Features | Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery Supply Chain Security: Remote Attestation Runtime BMC Protections System Lockdown |
| PC Health Monitoring | |
|---|---|
| Fan | Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors |
| Temperature | Monitoring for CPU and chassis environment |
| CPU | Monitors for CPU Cores, Chipset Voltages, Memory. 8+4 Phase-switching voltage regulator |
| Chassis | |
|---|---|
| Form Factor | 2U Rackmount |
| Model | CSE-GT214BC-R2K21BP |
| Dimensions and Weight | |
|---|---|
| Height | 8.78cm (88mm) |
| Width | 44.88cm (449mm) |
| Depth | 71.12cm (711.2mm) |
| Package | 24.79cm (H) x 62.61cm (W) x 115.01cm" (D) |
| Weight | Gross Weight: 88 lbs (39.9 kg) Net Weight: 68 lbs (30.8 kg) |
| Available Color | Silver |
| Front Panel | |
|---|---|
| LED | HDD activity LED Network activity LEDs Power status LED Universal Information (UID) LED |
| Buttons | Power On/Off button UID button |
| Expansion Slots (per Node) | |
|---|---|
| PCI-Express | Default: 2 PCIe 5.0 x16 LP slots |
| Storage (per Node) | |
|---|---|
| Drive Bays | Default: Total 6 bays 6 front hot-swap 2.5" NVMe/SATA drive bays |
| M.2 | 2 M.2 NVMe/SATA slots (M-key) |
| System Cooling | |
|---|---|
| Fans | 2x 16K RPM Heavy Duty 8cm Fans |
| Power Supply | |
|---|---|
| 2x 2200W Redundant Titanium Level (96%) power supplies | |
| Dimension (W x H x L) | 106.5 x 84 x 245.3 mm |
| AC Input | 100-127Vdc (1200W for the Rest of the World) 1200W: 100-127Vac / 50-60Hz 2090W: 180-220Vac / 50-60Hz (For UL/cUL Only) 200-220Vdc (1800W for the Rest of the World) 200-220Vdc (2090W for North America - UL & cUL) 1800W: 200-220Vac / 50-60Hz 220-230Vdc (1980W for the Rest of the World) 1980W: 220-230Vac / 50-60Hz 220-240Vdc (2200W for North America - UL & cUL) 2200W: 220-240Vac / 50-60Hz (For UL/cUL Only) 230-240Vdc (2090W for the Rest of the World) 2090W: 230-240Vdc / 50-60Hz (for CQC only) 2090W: 230-240Vac / 50-60Hz (for TUV/CB) |
| 12V SB | Max: 2A / Min: 0A |
| Output Type | Backplanes (gold finger) |
| Operating Environment | |
|---|---|
| RoHS | RoHS Compliant |
| Environmental Spec. | Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -30°C to 60°C (-22°F to 140°F) Operating Relative Humidity: 8% to 80% (non-condensing) Non-operating Relative Humidity: 8% to 90% (non-condensing) |
| Environmental / Recycling | |
|---|---|
| Recycle | Return Server-End of Life Product |
| Order Information | ||
|---|---|---|
| Manufacturer SKU | SYS-211GT-HNTR | |
| System Building | SYS-211GT-HNTR configured by Supermicro as Complete System | |
Supermicro SYS-211GT-HNTR Nitelikleri
| Add-on card form factor: | HH |
|---|---|
| Applications: | 5G/Telco, CDN, Cloud Computing, Edge/Cloud Computing Services, Edge Nodes, HPC |
| Backplane: | Yes |
| Backplane Interface: | SATA I, SATA II, SATA III, U.2 NVMe |
| Bluetooth Support: | None |
| CPU Codename: | Emerald Rapids, Sapphire Rapids |
| CPU Manufacturer: | Intel |
| CPU Socket: | 4677 |
| Card Reader Support: | No |
| Certification: | 80 Plus Titanium |
| Chassis Intrusion: | No |
| Computer group: | Server |
| Design: | Rackmount |
| Front I/O: | LED Indicators |
| Height units: | 2U |
| HotSwap/Fixed Drives: | Yes |
| HotSwap/Fixed Power Supply: | Hot-Swap Power Supply |
| IPMI / BMC: | Yes |
| Lighting: | LED |
| Motherboard Chipset: | C741 |
| Number of CPU sockets: | No |
| Number of RAM Pins: | 288 |
| Number of RAM Slots: | N/A |
| Onboard Graphic: | No |
| Onboard LAN: | No |
| Onboard Network Speed: | 1 Gb/s |
| PSU Power Wattage: | 2200W |
| Performance Class: | Enterprise-Class, High-End |
| Power Supply Cooler: | No |
| Pre-installed Components: | None |
| Pre-installed Software: | Windows 10, Windows 11, Windows Server |
| Product Model: | 211GT-HNTR |
| Quantity of Cooler: | 2 |
| Quantity of Power Supplies: | 2 |
| RAID Support: | No |
| RAM DIMM Type: | RDIMM |
| RAM ECC: | ECC |
| RAM registered/unregistered: | Registered |
| Redundant power: | Yes |
| Server Fanless: | No |
| Special Features: | LEDs |
| Specific Ports: | M.2 Ports, NVMe Ports, SATA Ports, U.2 Ports, USB Ports, VGA Ports |
| Suitability: | Server |
| Use case: | Cloud Computing, Cluster Node, Edge Server, High-Performance Computing (HPC) |
| Wi-Fi Support: | None |
| iGPU Manufacturer: | N/A |
