BA-DAE35-2LTCV4G-T-R | Happyware Dual Socket Epyc 9004 2U Server
Başlayan €3.207,74*
KDV artı nakliye masrafları dahil fiyatlar
Happyware BA-DAE35-2LTCV4G-T-R
Unleash Innovation with the BA-DAE35-2LTCV4G-T-R Barebone System
Discover the BA-DAE35-2LTCV4G-T-R by Happyware, a pioneer in advanced technology solutions. This barebone system caters to professionals and enthusiasts seeking exceptional performance and customisation.
Why Choose the BA-DAE35-2LTCV4G-T-R?
With Happyware's sterling reputation for quality and reliability, the BA-DAE35-2LTCV4G-T-R is a compelling choice for those looking to build a customized, robust computing system. Whether you're setting up a new server room or enhancing your personal workstation, this product offers the perfect foundation.
The compact and efficient design ensures that you get maximum power without sacrificing space. This versatile system is ready to be tailored to meet specific computing needs, delivering the performance and expandability that modern applications demand.
Key Applications:
• Big Data, Data Center
• Enterprise Server
• High-performance Computing, Virtualization
Future-proof your setup today! Call us now or register as a Happyware partner for exclusive deals, technical support, and tailored solutions. Don't wait—build the future with Happyware.
Happyware BA-DAE35-2LTCV4G-T-R Teknik Özellikleri
| Dual AMD EPYC 9004 CPU, 10x 3.5" drive bays (8x hot-swap & 2x fixed), 4x PCIe (LP), 2x 10GbE LAN, 2x 1000W Redundant PSUs |
| Dimensions (WxHxD, mm) | 2U 76 x 40 x 336 mm | |
| CPU | AMD EPYC™ 9004 series processors Dual processor, 5nm technology 84-core, 168 threads per processor cTDP u300W | |
| Socket | 2 x LGA 6096 Socket SP5 | |
| Chipset | System on Chip | |
| Memory | 24 x DIMM slots DDR5 memory supported only 12-Channel memory architecture per processor RDIMM modules up to 128GB supported 3DS RDIMM modules up to 256GB supported Memory speed: Up to 4800 MHz | |
| LAN | 2 x 10Gb/s BASE-T LAN ports (1 x Broadcom® BCM57416) NCSI function supported 1 x 10/100/1000 management LAN | |
| Video | Integrated in Aspeed® AST2600 2D Video Graphic Adapter with PCIe bus interface 1920x1200@60Hz 32bpp, DDR4 SDRAM | |
| Audio | N/A | |
| Storage | 2x 3.5" fixed drive bays 8x 3.5" hot-swap SAS3/SATA drive bays | |
| RAID | N/A | |
| Expansion Slots | 4x PCIe low-profile: | |
| Internal I/O | 1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 1 x 6-pin ATX 12V power connector 2 x MCIO 8i connectors 1 x M.2 slot 2 x CPU fan headers 5 x System fan headers 1 x USB 3.2 Gen1 header 1 x TPM header 1 x Front panel header 1 x HDD backplane board header 1 x PMBus connector 1 x IPMB connector 1 x Clear CMOS jumper 1 x BIOS recovery jumper 1 x Buzzer | |
| Rear I/O | 2 x USB 3.2 Gen1 1 x VGA 1 x COM 2 x RJ45 1 x MLAN 1 x ID button with LED | |
| Front I/O | Power On/Off button System Reset button | |
| LED Indicators | Power status LED HDD activity LED System Information LED Power Fail LED 2 Network Activity LEDs | |
| Backplane I/O | 8-port 2U SAS3 12Gbps TQ backplane, support up to 8x 3.5-inch SAS3/SATA3 HDD/SSD | |
| TPM | 1 x TPM header with SPI interface Optional TPM2.0 kit: CTM010 | |
| Power Supply | 1U 2x 1000W Redundant Titanium Single Output Power Supply w/ PMbus 96% | |
| System Management | Aspeed® AST2600 management controller GIGABYTE Management Console (AMI MegaRAC SP-X) web interface Dashboard HTML5 KVM Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.) Sensor Reading History Data FRU Information SEL Log in Linear Storage / Circular Storage Policy Hardware Inventory Fan Profile System Firewall Power Consumption Power Control LDAP / AD / RADIUS Support Backup & Restore Configuration Remote BIOS/BMC/CPLD Update Event Log Filter User Management Media Redirection Settings PAM Order Settings SSL Settings SMTP Settings | |
| OS Compatibility | Windows Server 2019 Red Hat Enterprise Linux Server 8.6 (x64) SUSE Linux Enterprise Server 15 SP4 (x64) Citrix Hypervisor 8.2.1 | |
| System Fans | 3 x heavy-duty PWM fans | |
| Packaging Dimensions (W x H x L) | 678 x 290 x 876 mm | |
| Color | Black | |
| Order Information | ||
| Manufacturer SKU | BA-DAE35-2LTCV4G-T-R | |
| System Building | BA-DAE35-2LTCV4G-T-R configured by Happyware as Complete System | |
Happyware BA-DAE35-2LTCV4G-T-R Nitelikleri
| Add-on card form factor: | HH |
|---|---|
| Applications: | Application-Optimized Solutions, Big Data, Data Center Applications, Data Center Optimized, Database, Enterprise Server, HPC, Virtualization |
| Backplane: | Yes |
| Backplane Interface: | SAS 1.0, SAS 2.0, SAS 3.0, SATA I, SATA II, SATA III |
| Bluetooth Support: | None |
| CPU Codename: | Genoa |
| CPU Manufacturer: | AMD |
| CPU Socket: | SP5 |
| Card Reader Support: | No |
| Certification: | 80 Plus Titanium |
| Chassis Intrusion: | No |
| Computer group: | Server |
| Design: | Rackmount |
| Front I/O: | LED Indicators |
| Height units: | 2U |
| HotSwap/Fixed Drives: | Yes |
| HotSwap/Fixed Power Supply: | Hot-Swap Power Supply |
| IPMI / BMC: | Yes |
| Lighting: | LED |
| Motherboard Chipset: | System on Chip |
| Number of CPU sockets: | No |
| Number of RAM Pins: | 288 |
| Number of RAM Slots: | N/A |
| Onboard Controller: | Broadcom BCM57416 |
| Onboard Graphic: | Yes |
| Onboard LAN: | Yes |
| Onboard Network Speed: | 10 Gb/s |
| PSU Power Wattage: | 1000W |
| Performance Class: | Enterprise-Class, High-End |
| Power Supply Cooler: | No |
| Pre-installed Components: | None |
| Pre-installed Software: | Citrix Hypervisor (formerly XenServer), Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu, VMware ESXi, Windows Server |
| Product Model: | DAE35-2LTCV4G-T-R |
| Quantity of Cooler: | 3 |
| Quantity of Power Supplies: | 2 |
| RAID Support: | No |
| RAM DIMM Type: | RDIMM |
| RAM ECC: | ECC |
| RAM registered/unregistered: | Registered |
| Redundant power: | Yes |
| Server Fanless: | No |
| Special Features: | LEDs |
| Specific Ports: | M.2 Ports, SAS Ports, SATA Ports, USB Ports, VGA Ports |
| Suitability: | Server |
| Use case: | Application Hosting, Database Server, High-Performance Computing (HPC), Virtualization |
| Wi-Fi Support: | None |
| iGPU Manufacturer: | N/A |
