G493-ZB3-AAP1 | Gigabyte Dual Socket Epyc 9004 4U Server
Başlayan €17.683,57*
KDV artı nakliye masrafları dahil fiyatlar
Gigabyte G493-ZB3-AAP1
Elevate Your Experience with the Gigabyte G493-ZB3-AAP1 Barebone System
Introducing the future of computing with the G493-ZB3-AAP1, expertly crafted by Gigabyte. Designed for tech enthusiasts and professional creators alike, this powerhouse of innovation serves as the perfect foundation for building your dream custom PC. It is designed to meet the demands of the modern enterprise, delivering unparalleled performance and efficiency for AI, machine learning, and high-performance computing tasks. With its powerful combination of AMD EPYC™ 9004 processors and advanced GPU support, this server is tailored for businesses seeking to maximise computational power and operational efficiency in their data centre environment.
Why Choose the Gigabyte G493-ZB3-AAP1?
Whether you're a gamer, content creator, or business professional, this product is designed to adapt to your unique requirements. Let your creativity shine by adding your preferred components, ensuring a personalized experience tailored just for you. Experience unprecedented processing speed and efficient workflow with the Barebone G493-ZB3-AAP1. With its robust design and cutting-edge technology, it provides the versatility and reliability needed to tackle even the most demanding tasks effortlessly.
What sets this system apart is its energy-efficient architecture, which reduces overall power consumption while maintaining top-tier performance. This makes it an optimal choice for businesses looking to scale their operations without incurring hefty energy costs. Equipped with 8 x PCIe Gen5 slots and support for the latest NVIDIA-Certified Systems™ technology, the G493-ZB3-AAP1 can handle the most intensive GPU-accelerated applications, ensuring that your enterprise is well-equipped for future growth.
Key Applications:
• AI / AI Training / AI Inference
• Visual Computing
• High performance Computing
Ready to elevate your business’s AI and HPC capabilities? Reach out to Happyware now and discover how the Gigabyte G493-ZB3-AAP1 can power your next-generation workloads. Our team is here to guide you in unlocking unparalleled performance, scalability, and efficiency for your operations. Don’t wait—take the next step toward transforming your business with the right technology today!
Gigabyte G493-ZB3-AAP1 Teknik Özellikleri
| Dual AMD EPYC 9004 Series CPU, 12x 2.5" hot-swap drive bays, 8x PCIe (FHFL) for GPUs + 10x PCIe (LP), 4x 3000W redundant PSUs |
| Dimensions (WxHxD, mm) | 4U 448 x 176 x 880 | |
| Motherboard | MZB3-G41 | |
| CPU | AMD EPYC™ 9004 Series processors AMD EPYC™ 9004 Series processors with AMD 3D V-Cache™ Technology Dual processor, 5nm technology *Up to 128-core, 256 threads per processor cTDP up to 300W at ambient 35°C *cTDP supported up to 400W under limited thermal conditions. Note: If only 1 CPU is installed, some PCI-E or memory functions might be unavailable | |
| Socket | 2 x LGA 6096 Socket SP5 | |
| Chipset | System on Chip | |
| Memory | 48 x DIMM slots DDR5 memory supported only 12-Channel memory architecture RDIMM modules up to 96GB supported 3DS RDIMM modules up to 256GB supported Memory speed: Up to 4800 MHz (1DPC), 3600 MHz (2DPC) | |
| LAN | Front side: 2 x 1Gb/s BASE-T LAN ports (1 x Intel® I350-AM2) NCSI function supported 1 x 10/100/1000 management LAN | |
| Video | Integrated in Aspeed® AST2600 2D Video Graphic Adapter with PCIe bus interface 1920x1200@60Hz 32bpp, DDR4 SDRAM | |
| Storage | Front side: 12 x 2.5" Gen5 NVMe/SATA/SAS hot-swappable bays - (6 x NVMe from CPU_0, 6 x NVMe from CPU_1) SAS card is required for SAS devices support | |
| SAS | Depends on Add-on SAS card | |
| RAID | N/A | |
| Expansion Slots | 4 x PCIe x16 (Gen5 x16) FHFL slots, from PEX89144_0, for GPUs 4 x PCIe x16 (Gen5 x16) FHFL slots, from PEX89144_1, for GPUs 4 x PCIe x16 (Gen5 x16) low-profile slots, from PEX89144_0 4 x PCIe x16 (Gen5 x16) low-profile slots, from PEX89144_1 1 x PCIe x16 (Gen5 x16) low-profile slot on front side, from CPU_0 1 x PCIe x16 (Gen5 x16) low-profile slot on front side, from CPU_1 - System is validated for population with a uniform GPU model - Support is not provided for mixed GPU populations 1 x M.2 slot: - M-key - PCIe Gen3 x4, from CPU_0 - Supports 2280/22110 cards 1 x M.2 slot: - M-key - PCIe Gen3 x4, from CPU_1 - Supports 2280/22110 cards | |
| Internal I/O | 2 x M.2 slots 1 x TPM header | |
| Front I/O | 2 x USB 3.2 Gen1 1 x VGA 2 x RJ45 1 x MLAN 1 x Power button with LED 1 x ID button with LED 1 x Reset button 1 x NMI button 1 x System status LED 1 x HDD access LED | |
| Rear I/O | N/A | |
| Backplane I/O | Speed and bandwidth: PCIe Gen5 x4 or SATA 6Gb/s or SAS 12Gb/s | |
| TPM | 1 x TPM header with SPI interface Optional TPM2.0 kit: CTM010 | |
| Power Supply | 3+1 3000W (240V) 80 PLUS Titanium redundant power supplies AC Input: - 100-127V~/ 15.5A, 50-60Hz - 200-220V~/ 15.5A, 50-60Hz - 220-240V~/ 15.5A, 50-60Hz DC Input: - 240Vdc/ 15.5A DC Output: - Max 1000W/ 100-127V~ + 12.2V/ 81A + 12Vsb/ 3A - Max 2600W/ 200-220V~ + 12.2V/ 213A + 12Vsb/ 3A - Max 3000W/ 220-240V~ + 12.2V/ 240A + 12Vsb/ 3A Note: The system power supply requires C19 type power cord | |
| System Management | Aspeed® AST2600 management controller GIGABYTE Management Console (AMI MegaRAC SP-X) web interface Dashboard HTML5 KVM Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.) Sensor Reading History Data FRU Information SEL Log in Linear Storage / Circular Storage Policy Hardware Inventory Fan Profile System Firewall Power Consumption Power Control Advanced power capping LDAP / AD / RADIUS Support Backup & Restore Configuration Remote BIOS/BMC/CPLD Update Event Log Filter User Management Media Redirection Settings PAM Order Settings SSL Settings SMTP Settings | |
| OS Compatibility | Windows Server 2019 or later Windows Server 2022 or later Red Hat Enterprise Linux 8.6 (x64) or later Red Hat Enterprise Linux 8.7 (x64) or later Red Hat Enterprise Linux 8.8 (x64) or later Red Hat Enterprise Linux 9.0 (x64) or later Red Hat Enterprise Linux 9.1 (x64) or later Red Hat Enterprise Linux 9.2 (x64) or later SUSE Linux Enterprise Server 15 SP4 (x64) or later SUSE Linux Enterprise Server 15 SP5 (x64) or later Ubuntu 20.04.5 LTS (x64) or later Ubuntu 20.04.6 LTS (x64) or later Ubuntu 22.04 LTS (x64) or later Ubuntu 22.04.1 LTS (x64) or later Ubuntu 22.04.2 LTS (x64) or later Ubuntu 22.04.3 LTS (x64) or later VMware ESXi 7.0 Update 3i or later VMware ESXi 8.0 or later VMware ESXi 8.0 Update 1 or later Citrix Hypervisor 8.2 LTSR CU1 or later | |
| System Fans | 12 x 60x60x38mm (23,000rpm) | |
| Operating Properties | Operating temperature: 10°C to 35°C Operating humidity: 8%-80% (non-condensing) Non-operating temperature: -40°C to 60°C Non-operating humidity: 20%-95% (non-condensing) | |
| Packaging Dimensions | 1200 x 800 x 444 mm w/ pallet | |
| Packaging Content | 1 x G493-ZB3 2 x CPU fansinks 1 x L-shape Rail kit | |
| Part Numbers | - Barebone package: 6NG493ZB3DR000AAP1* - Motherboard: 9MZB3G41UR-000 - L-shape Rail kit: 25HB2-A96100-K0R - CPU fansink: 25ST0-0Z6023-C1R/25ST0-0Z6024-C1R - Backplane board - CBP10C2: 9CBP10C2NR-00 - Fan module: 25ST2-663823-F1R - PCIe bridge board - CPBG000: 9CPBG000NR-00 - PCIe switch board - CPB4AG0: 9CPB4AG0NR-00 - G-SC Module - CDCG110: 9CDCG110UR-00 - Power supply: 25EP0-230005-G1S | |
| Optional parts | - C19 power cord 125V/15A (US): 25CP1-018000-Q0R - C19 power cord 250V/16A (EU): 25CP3-01830H-Q0R - RMA packaging: 6NG493ZB3SR-RMA-A100 | |
| Order Information | ||
| Manufacturer SKU | G493-ZB3 (6NG493ZB3DR000AAP1) | |
| System Building | G493-ZB3 (6NG493ZB3DR000AAP1) can be configured individually | |
Gigabyte G493-ZB3-AAP1 Nitelikleri
| Add-on card form factor: | FH, HH |
|---|---|
| Applications: | AI / Deep Learning, AI Inference and Machine Learning, AI inferencing, GPU server, HPC, Visual Computing |
| Backplane: | Yes |
| Backplane Interface: | PCIe Gen 5, SAS 1.0, SAS 2.0, SAS 3.0, SATA I, SATA II, SATA III, U.2 NVMe |
| Bluetooth Support: | None |
| CPU Codename: | Genoa |
| CPU Manufacturer: | AMD |
| CPU Socket: | SP5 |
| Card Reader Support: | No |
| Certification: | 80 Plus Titanium |
| Chassis Intrusion: | No |
| Computer group: | Server |
| Design: | Rackmount |
| Front I/O: | LED Indicators, USB Type-A |
| GPU quantity per node: | 8 |
| Height units: | 4U |
| HotSwap/Fixed Drives: | Yes |
| HotSwap/Fixed Power Supply: | Hot-Swap Power Supply |
| IPMI / BMC: | Yes |
| Lighting: | LED |
| Motherboard Chipset: | System on Chip |
| Number of CPU sockets: | No |
| Number of RAM Pins: | 288 |
| Number of RAM Slots: | N/A |
| Onboard Graphic: | Yes |
| Onboard LAN: | Yes |
| Onboard Network Speed: | 1 Gb/s |
| PSU Power Wattage: | 3000W |
| Performance Class: | Enterprise-Class, High-End |
| Power Supply Cooler: | Yes |
| Pre-installed Components: | None |
| Pre-installed Software: | Citrix Hypervisor (formerly XenServer), Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu, VMware ESXi, Windows Server |
| Product Model: | G493-ZB3-AAP1 |
| Product Version: | Rev-1.x |
| Quantity of Cooler: | 12 |
| Quantity of Power Supplies: | 4 |
| RAID Support: | Yes |
| RAM DIMM Type: | RDIMM |
| RAM ECC: | ECC |
| RAM registered/unregistered: | Registered |
| Redundant power: | Yes |
| Server Fanless: | No |
| Special Features: | LEDs |
| Specific Ports: | M.2 Ports, NVMe Ports, SAS Ports, SATA Ports, U.2 Ports, USB Ports, VGA Ports |
| Suitability: | Server |
| Use case: | Database Server, Deep Learning - Machine Learning, GPGPU, High-Performance Computing (HPC), Virtualization |
| Wi-Fi Support: | None |
| iGPU Manufacturer: | N/A |
