H263-S62-LAN1 | Gigabyte Dual Socket Xeon Scalable 2U Server
Ürün numarası: TR1B8897-830205
|
Üretici numarası: 6NH263S62DR000LAN1
Başlayan €14.618,36*
KDV artı nakliye masrafları dahil fiyatlar
Gigabyte H263-S62-LAN1
Ensure Long-Term Viability with the Gigabyte H263-S62-LAN1 Barebone System
Introducing the Gigabyte H263-S62-LAN1 is a robust 2U server designed for efficiency, power, and scalability. Built to meet the growing demands of data-heavy environments, this server delivers exceptional performance with support for multiple processors and expansive memory options. Ideal for high-performance workloads, including artificial intelligence (AI) and big data applications, the H263-S62-LAN1 offers the reliability businesses need to accelerate their operations while reducing operational costs.
Why Choose the Gigabyte H263-S62-LAN1?
The Gigabyte H263-S62-LAN1 stands out as a high-density server solution, powered by 5th/4th Gen Intel® Xeon® Scalable processors. Its 2U 4-node design, combined with 24-bay Gen4 NVMe/SATA/SAS support and 2600W DLC, is perfect for businesses aiming for scalable, high-performance operations. It is engineered for AI training, machine learning, and big data analytics, offering optimal performance while maintaining energy efficiency.
The server’s enhanced platform leverages AI acceleration engines built into Intel’s latest Xeon processors. These processors provide a significant performance boost, optimising CPU performance per watt and enabling data movement at twice the speed with PCIe Gen5. Designed to handle high-performance workloads, it supports fast accelerators, NVMe drives, and DDR5 memory, ensuring rapid processing and scalability for demanding applications.
Key Applications:
• High performance Computing
• Hyperconverged Infrastructure
Future-proof your business with the Gigabyte H263-S62-LAN1. Contact Happyware today to discover how this high-performance server can drive your IT infrastructure forward.
Gigabyte H263-S62-LAN1 Teknik Özellikleri
| Dual Intel Xeon Scalable 5th/4th Gen CPU, 4 Nodes, 6x 2.5" hot-swap drive bays, 2x PCIe (1x LP, 1x OCP 3.0), 2x 2600W redundant PSUs |
| Dimensions (WxHxD, mm) | 2U 4 Nodes - Rear access 440 x 87.5 x 840 | |
| Motherboard | MS63-HD1 | |
| CPU | 5th Generation Intel® Xeon® Scalable Processors 4th Generation Intel® Xeon® Scalable Processors Intel® Xeon® CPU Max Series Dual processor per node, TDP up to 385W Note: If only 1 CPU is installed, some PCIe or memory functions might be unavailable | |
| Socket | 8 x LGA 4677 Socket E | |
| Chipset | Intel® C741 Chipset | |
| Memory | 64 x DIMM slots DDR5 memory supported 8-Channel memory architecture 5th Gen Intel® Xeon®: RDIMM: Up to 5600 MT/s 4th Gen Intel® Xeon®: RDIMM: Up to 4800 MT/s Intel® Xeon® Max Series: RDIMM: Up to 4800 MT/s | |
| LAN | Rear: 4 x 10/100/1000 Mbps Management LAN 1 x CMC Management LAN | |
| Video | Integrated in Aspeed® AST2600 x 4 - 4 x VGA ports | |
| Storage | Front hot-swap: 24 x 2.5" Gen4 NVMe/SATA/SAS - (NVMe from CPU_1) Optional internal M.2 (CMTP061 x 4): 4 x M.2 (2280/22110), PCIe Gen4 x4, from CPU_1 SAS card is required for SAS devices support | |
| SAS | Require SAS add-in cards | |
| RAID | Intel® SATA RAID 0/1/10/5 Onboard VROC key header Support optional RAID add-in cards | |
| Expansion Slots | Per Node: Riser Card CRSH01U x 4: - 4 x LP x16 (Gen5 x16), from CPU_0 4 x OCP NIC 3.0 (Gen5 x16), from CPU_0 - Support NCSI function | |
| Front I/O | 4 x Power buttons with LED 4 x ID buttons with LED 4 x Reset buttons 4 x System status LEDs 1 x CMC status LED 1 x CMC reset button | |
| Rear I/O | 8 x USB 3.2 Gen1 ports (Type-A) 4 x VGA ports 4 x MLAN ports 4 x ID buttons with LED 1 x CMC port | |
| Backplane I/O | Speed and bandwidth: PCIe Gen4 x4 or SATA 6Gb/s or SAS 12Gb/s | |
| Security Modules | 1 x TPM header with SPI interface Optional TPM2.0 kit: CTM010 | |
| Power Supply | Dual 2600W 80 PLUS Titanium redundant power supply Available for 2+1 redundant power supply configuration (optional) AC Input: - 100-127V~/ 15A, 50-60Hz - 200-240V~/ 15A, 50-60Hz DC Input: (Only for China) - 240Vdc/ 15A DC Output: - Max 1000W/ 100-127V~ +12.2V/ 82A +12.2Vsb/ 4.5A - Max 2600W/ 200-240V~ or 240Vdc Input +12.2V/ 213A +12.2Vsb/ 4.5A | |
| System Management | Aspeed® AST2600 Baseboard Management Controller Aspeed® AST2520 Chassis Management Controller GIGABYTE Management Console web interface Dashboard HTML5 KVM Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.) Sensor Reading History Data FRU Information SEL Log in Linear Storage / Circular Storage Policy Hardware Inventory Fan Profile System Firewall Power Consumption Power Control LDAP / AD / RADIUS Support Backup & Restore Configuration Remote BIOS/BMC/CPLD Update Event Log Filter User Management Media Redirection Settings PAM Order Settings SSL Settings SMTP Settings | |
| OS Compatibility | Windows Server 2019 Windows Server 2022 Red Hat Enterprise Linux 8.6 (x64) or later Red Hat Enterprise Linux 8.7 (x64) or later Red Hat Enterprise Linux 9.0 (x64) or later Red Hat Enterprise Linux 9.1 (x64) or later Red Hat Enterprise Linux 9.2 (x64) or later SUSE Linux Enterprise Server 15 SP4 (x64) or later Ubuntu 22.04 LTS (x64) or later Ubuntu 22.04.1 LTS (x64) or later Ubuntu 22.04.2 LTS (x64) or later VMware ESXi 7.0 Update 3i or later VMware ESXi 8.0 or later VMware ESXi 8.0 Update 1 or later Citrix Hypervisor 8.2 LTSR CU1 or later | |
| System Fans | 4 x 80x80x38mm (18,300rpm) | |
| Operating Properties | Operating temperature: 10°C to 40°C Operating humidity: 8-80% (non-condensing) Non-operating temperature: -40°C to 60°C Non-operating humidity: 20%-95% (non-condensing) Note: To ensure system stability and prevent condensation, when the relative humidity exceeds 50%, the coolant inlet temperature must be higher than the dry-bulb temperature and it should not exceed 40°C. | |
| Weight | Net Weight: 47.66 kg Gross Weight: 49.96 kg | |
| Packaging Dimensions | w/ cold plate loops: 1185 x 705 x 409 mm w/o cold plate loops: 1176 x 709 x 322 mm | |
| Packaging Content | 1 x H263-S62-LAN1 4 x CoolIT CPU cold plate loops 24 x Carriers 1 x 3-Section Rail kit | |
| Part Numbers | - Barebone w/ cold plates (5th/4th Gen): 6NH263S62DR000LBN1* - Barebone w/ cold plates (4th Gen): 6NH263S62DR000LAN1* - Barebone w/o cold plates (5th/4th Gen): 6NH263S62DZ000LBN1* - Barebone w/o cold plates (4th Gen): 6NH263S62DZ000LAN1* - Motherboard: 9MS63HD1UR-000* - 3-Section Rail kit: 25HB2-A66125-K0R - CoolIT CPU cold plate loop: 25ST7-100006-C4R - Front panel board - CFPH004: 9CFPH004NR-00* - Backplane board - CBPH7O1: 9CBPH7O1NR-00* - Fan module: 25ST2-88382P-S1R - Riser card - CRSH01U: 9CRSH01UNR-00* - Power supply: 25EP0-226001-G1S Optional parts: - C19 power cord 125V/15A (US): 25CP1-018000-Q0R - C19 power cord 250V/16A (EU): 25CP3-01830H-Q0R - C19 power cord 125V/15A (JP): 25CPA-01830B-Q0R - M.2 riser card - CMTP061: 9CMTP061NR-00* - Ring topology kit (10-kit package): 6NH263S62S1000AAN11 - GIGABYTE CPU cold plate loop: 25H26-3S62000-E01X (QPA:4) - GIGABYTE 2U4N Manifold: 25H27-3Z80000-E07X (1 set per rack) - Motivair CPU cold plate loop: 25ST7-10000B-M4R (QPA:4) - CoolIT leak sensor board: 6NH263S62S1000LAN11 (QPA:4) - RMA packaging: 6NH263S62SR-RMA-L100 | |
| Order Information | ||
| Manufacturer SKU | H263-S62 (6NH263S62DR000LAN1) | |
| System Building | H263-S62 (6NH263S62DR000LAN1) can be configured individually | |
Gigabyte H263-S62-LAN1 Nitelikleri
| Add-on card form factor: | HH, OCP 3.0 |
|---|---|
| Applications: | Enterprise Applications, Enterprise Server, HPC, High End Enterprise Server, High Performance Computing, Hyperconverged Storage, Hyperscale / Hyperconverged, Virtualization |
| Backplane: | Yes |
| Backplane Interface: | PCIe Gen 4, SAS 1.0, SAS 2.0, SAS 3.0, SATA I, SATA II, SATA III |
| Bluetooth Support: | None |
| CPU Codename: | Emerald Rapids, Sapphire Rapids |
| CPU Manufacturer: | Intel |
| CPU Socket: | 4677 |
| Card Reader Support: | No |
| Certification: | 80 Plus Titanium |
| Chassis Intrusion: | No |
| Computer group: | Server |
| Design: | Rackmount |
| Front I/O: | LED Indicators |
| Height units: | 2U |
| HotSwap/Fixed Drives: | Yes |
| HotSwap/Fixed Power Supply: | Hot-Swap Power Supply |
| IPMI / BMC: | Yes |
| Lighting: | LED |
| Motherboard Chipset: | C741 |
| Number of CPU sockets: | No |
| Number of RAM Slots: | N/A |
| Onboard Graphic: | No |
| Onboard LAN: | No |
| Onboard Network Speed: | 1 Gb/s |
| PSU Power Wattage: | 2600W |
| Performance Class: | Enterprise-Class, High-End |
| Power Supply Cooler: | No |
| Pre-installed Components: | None |
| Pre-installed Software: | Citrix Hypervisor (formerly XenServer), Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu, VMware ESXi, VMware vCenter, Windows Server |
| Product Model: | H263-S62-LAN1 |
| Quantity of Cooler: | 4 |
| Quantity of Power Supplies: | 2 |
| RAID Support: | Yes |
| RAM DIMM Type: | RDIMM |
| RAM ECC: | ECC |
| RAM registered/unregistered: | Registered |
| Redundant power: | Yes |
| Server Fanless: | No |
| Special Features: | LEDs, Suitable for continuous operation |
| Specific Ports: | M.2 Ports, NVMe Ports, SAS Ports, SATA Ports, U.2 Ports, USB Ports, VGA Ports |
| Suitability: | Server |
| Use case: | Cluster Node, High-Performance Computing (HPC), Virtualization |
| Wi-Fi Support: | None |
| iGPU Manufacturer: | N/A |
