R263-S33-AAF1 | Gigabyte Single Socket Xeon Scalable 2U Server
Başlayan €4.501,94*
KDV artı nakliye masrafları dahil fiyatlar
Gigabyte R263-S33-AAF1
Elevate Your Performance with the Gigabyte R263-S33-AAF1 Barebone System
Unleash exceptional computing power with the Gigabyte R263-S33-AAF1 Barebone System. Built for performance and reliability, this system is powered by the advanced Intel C741 chipset and designed to support Intel® Xeon® processors through the LGA 4677 (Socket E) socket. Ideal for data centers, professional workstations, and demanding applications, the R263 delivers powerful multi-core performance, ensuring efficiency in handling critical tasks. Whether you need high-speed processing for large datasets or robust performance for complex applications, the Gigabyte R263 provides the foundation for next-generation computing power, supporting Intel® Xeon® processors for unparalleled reliability and efficiency.
Why Choose the Gigabyte R263-S33-AAF1?
The Gigabyte R263-S33-AAF1 Barebone System stands out for its exceptional scalability and flexible configurations, tailored to meet the needs of your most demanding environments. With support for various DDR4-SDRAM memory options, including 2GB, 4GB, 8GB, 16GB, 32GB, 64GB, and 128GB, this system allows you to optimise your setup for a range of performance requirements. Whether you’re scaling up for high-performance computing, handling large data volumes, or managing multiple virtual machines, the R263 offers the versatility and power you need.
Renowned for quality and innovation, Gigabyte delivers reliability and performance, making the R263 a trusted solution for professionals who demand the best in performance, reliability, and flexibility. Unlock new productivity levels and meet your business goals faster with the Gigabyte R263-S33-AAF1.
Key Applications:
• AI / AI Training / AI Inference
• Visual Computing
• Networking
• Hybrid / Private Cloud Server
Are you prepared to optimise your system’s performance to meet the demands of modern workloads? Reach out to Happyware today to explore how the Gigabyte R263-S33-AAF1 Barebone System can enhance your enterprise's computational capabilities. Let us help you unlock the full potential of your hardware investment, optimising for maximum throughput and minimal latency across your enterprise’s operations.
Gigabyte R263-S33-AAF1 Teknik Özellikleri
| Single Intel Xeon Scalable 4th Gen CPU, 12x 3.5/2.5" hot-swap drive bays, 3x PCIe (FHFL) for GPUs, 2x OCP 3.0, 1x 1GbE LAN, 2x 2400W Redundant PSUs |
| Dimensions (WxHxD, mm) | 2U 438 x 87.5 x 700 | |
| Motherboard | MS33-DC0 | |
| CPU | 4th Generation Intel® Xeon® Scalable Processors Intel® Xeon® CPU Max Series Intel® Xeon® Platinum Processor, Intel® Xeon® Gold Processor, Intel® Xeon® Silver Processor Single processor, CPU TDP up to 350W | |
| Socket | 1 x LGA 4677 Socket E | |
| Chipset | Intel® C741 Chipset | |
| Memory | 16 x DIMM slots DDR5 memory supported only 8-Channel memory architecture RDIMM modules up to 128GB supported 3DS RDIMM modules up to 256GB supported Memory speed: Up to 4800 MHz (1DPC), 4400 MHz (2DPC) | |
| LAN | Rear side: 1 x 1Gb/s LAN port (1 x Intel® I210-AT) Supports NCSI function 1 x 10/100/1000 management LAN | |
| Video | Integrated in Aspeed® AST2600 2D Video Graphic Adapter with PCIe bus interface 1920x1200@60Hz 32bpp, DDR4 SDRAM | |
| Storage | Front side: 12 x 3.5"/2.5" SATA/SAS hot-swappable bays SAS card is required for SAS devices support | |
| SAS | Depends on SAS Add-on card | |
| RAID | Intel® SATA RAID 0/1/10/5 | |
| Expansion Slots | Riser Card CRS201C: - 1 x PCIe x16 (Gen5 x16) FHFL slot, from CPU, for GPUs Riser Card CRS201D: - 1 x PCIe x16 (Gen5 x16) FHFL slot, from CPU, for GPUs Riser Card CRS2018: - 1 x PCIe x16 (Gen5 x16) FHFL slot, from CPU, for GPUs 2 x OCP 3.0 slots with PCIe Gen5 x16 bandwidth, from CPU Support NCSI function 1 x M.2 slot: - M-key - PCIe Gen3 x4, from PCH - Supports 2280/22110 cards | |
| Internal I/O | 1 x M.2 slot 1 x TPM header 1 x VROC connector 2 x OCP 3.0 mezzanine slots | |
| Front I/O | 2 x USB 3.2 Gen1 1 x Power button with LED 1 x ID button with LED 1 x NMI button 1 x Reset button 1 x LAN activity LED 1 x HDD activity LED 1 x System status LED | |
| Rear I/O | 2 x USB 3.2 Gen1 1 x Mini-DP 1 x RJ45 1 x MLAN 1 x ID button with LED | |
| Backplane I/O | Speed and bandwidth: SATA 6Gb/s or SAS 12Gb/s | |
| TPM | 1 x TPM header with SPI interface Optional TPM2.0 kit: CTM010 | |
| Power Supply | Dual 2400W (240V) 80 PLUS Platinum redundant power supply AC Input: - 100-127V~/ 12.5A, 47-63Hz - 180-240V~/ 14.5A, 47-63Hz DC Input: - 240Vdc/ 12A DC Output: - Max 1000W/ 100-127V~ + 12V/ 84A + 12Vsb/ 3A - Max 2200W/ 180-200V~ + 12V/ 180A + 12Vsb/ 3.5A - Max 2400W/ 200-240V~ or 240Vdc + 12V/ 197A + 12Vsb/ 3.5A Note: The system power supply requires C19 power cord. The default power supply is based on a basic system configuration | |
| System Management | Aspeed® AST2600 management controller GIGABYTE Management Console (AMI MegaRAC SP-X) web interface Dashboard HTML5 KVM Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.) Sensor Reading History Data FRU Information SEL Log in Linear Storage / Circular Storage Policy Hardware Inventory Fan Profile System Firewall Power Consumption Power Control LDAP / AD / RADIUS Support Backup & Restore Configuration Remote BIOS/BMC/CPLD Update Event Log Filter User Management Media Redirection Settings PAM Order Settings SSL Settings SMTP Settings | |
| OS Compatibility | Windows Server 2019 | |
| System Fans | 4 x 80x80x38mm (18,300rpm) | |
| Operating Properties | Operating temperature: 10°C to 35°C Operating humidity: 8%-80% (non-condensing) Non-operating temperature: -40°C to 60°C Non-operating humidity: 20%-95% (non-condensing) | |
| Packaging Dimensions | 989 x 594 x 279 mm | |
| Packaging Content | 1 x R263-S33 1 x CPU heatsink 1 x Mini-DP to D-Sub cable 3 x Carrier clips 1 x Rail kit | |
| Part Numbers | - Barebone package: 6NR263S33DR000AAF1* - Motherboard: 9MS33DC0UR-000 - Rail kit: 25HB2-3A0203-K0R - CPU heatsink: 25ST1-4Z3200-S7R - M.2 heatsink: 12SP2-11000E-00R - Front panel board: 9CFP2001NR-00 - Backplane board: 9CBP20C5NR-00 - Fan module: 25ST2-88382T-S1R - Riser card - CRS201C: 9CRS201CNR-00 - Riser card - CRS201D: 9CRS201DNR-00 - Riser card - CRS2018: 9CRS2018NR-00 - Mini-DP to D-Sub cable: 25CRN-200801-K1R - GPU cable (6P+2P) 350mm: 25CRI-350305-Y4R - GPU cable (6P+2P) 480mm: 25CRI-480300-Y4R - C19 power cord 125V/15A (US): 25CP1-018000-Q0R (optional) - C19 power cord 250V/16A (EU): 25CP3-01830H-Q0R (optional) - C19 power cord 125V/15A (JP): 25CPA-01830B-Q0R (optional) - Power supply: 25EP0-224000-D0S | |
| Order Information | ||
| Manufacturer SKU | R263-S33 (6NR263S33DR000AAF1) | |
| System Building | R263-S33 (6NR263S33DR000AAF1) can be configured individually | |
Gigabyte R263-S33-AAF1 Nitelikleri
| Add-on card form factor: | FH, HH, OCP 3.0 |
|---|---|
| Applications: | AI / Deep Learning, AI Inference and Machine Learning, AI inferencing, Big Data, Cloud Computing, Database, Networking, Virtualization, Visual Computing |
| Backplane: | Yes |
| Backplane Interface: | PCIe Gen 4, SAS 1.0, SAS 2.0, SAS 3.0, SATA I, SATA II, SATA III |
| Bluetooth Support: | None |
| CPU Codename: | Emerald Rapids, Sapphire Rapids |
| CPU Manufacturer: | Intel |
| CPU Socket: | 4677 |
| Card Reader Support: | No |
| Certification: | 80 Plus Platinum |
| Chassis Intrusion: | No |
| Computer group: | Server |
| Design: | Rackmount |
| Front I/O: | LED Indicators, USB Type-A |
| GPU quantity per node: | 3 |
| Height units: | 2U |
| HotSwap/Fixed Drives: | Yes |
| HotSwap/Fixed Power Supply: | Hot-Swap Power Supply |
| IPMI / BMC: | Yes |
| Lighting: | LED |
| Motherboard Chipset: | C741 |
| Number of CPU sockets: | No |
| Number of RAM Pins: | 288 |
| Number of RAM Slots: | N/A |
| Onboard Graphic: | Yes |
| Onboard LAN: | Yes |
| Onboard Network Speed: | 1 Gb/s |
| PSU Power Wattage: | 1200W |
| Performance Class: | Enterprise-Class, High-End |
| Power Supply Cooler: | No |
| Pre-installed Components: | None |
| Pre-installed Software: | Citrix Hypervisor (formerly XenServer), Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu, VMware ESXi, Windows Server |
| Product Model: | R263-S33-AAF1 |
| Quantity of Cooler: | 4 |
| Quantity of Power Supplies: | 2 |
| RAID Support: | Yes |
| RAM DIMM Type: | RDIMM |
| RAM ECC: | ECC |
| RAM registered/unregistered: | Registered |
| Redundant power: | Yes |
| Server Fanless: | No |
| Special Features: | LEDs |
| Specific Ports: | Display Ports, M.2 Ports, SAS Ports, SATA Ports, USB Ports |
| Suitability: | Server |
| Use case: | Cloud Computing, Deep Learning - Machine Learning, Visual Computing |
| Wi-Fi Support: | None |
