BA-SAE35-2LTCV4-R | Happyware Single Socket Epyc 9004 2U Server
Ürün numarası: TR8B3449-210367
|
Üretici numarası: BA-SAE35-2LTCV4-R
Başlayan €2.072,48*
KDV artı nakliye masrafları dahil fiyatlar
Happyware BA-SAE35-2LTCV4-R
Unleash the Power with the Happyware BA-SAE35-2LTCV4-R Barebone System
Step into the future of computing with the revolutionary BA-SAE35-2LTCV4-R, crafted by Happyware, a name synonymous with quality and innovation. Designed for those who demand high performance and reliability, this barebone system delivers exceptional functionality in a compact, sleek design that elevates both aesthetics and efficiency.
Why Choose Happyware BA-SAE35-2LTCV4-R?
Happyware is synonymous with quality and technological advancement. Their commitment to creating products that cater to modern-day needs is evident in every detail of the BA-SAE35-2LTCV4-R. It's more than just a product, it's a game-changer in the world of technology.
With Happyware’s commitment to excellence, the BA-SAE35-2LTCV4-R stands as a versatile solution for Big Data, virtualisation, and enterprise applications. Tailored for modern computing demands, it redefines performance standards.
Key Applications:
• Big Data, Data Center, Database
• Enterprise Server, Networking
• High-performance Computing, Virtualization
Future-proof your operations—call us today or register as a Happyware partner to unlock exclusive benefits and unparalleled support.
Happyware BA-SAE35-2LTCV4-R Teknik Özellikleri
| BA-SAE35-2LTCV4-R | Single AMD EPYC 9004 CPU, 10x 3.5" drive bays (8x hot-swap, 2x fixed), 5x PCIe (LP), 2x 1GbE LAN, 2x 1000W redundant PSUs |
| BA-SAE35-2LTCV4-T-R | Single AMD EPYC 9004 CPU, 10x 3.5" drive bays (8x hot-swap, 2x fixed), 5x PCIe (LP), 2x 10GbE LAN, 2x 1000W redundant PSUs |
| Processor | |
|---|---|
| CPU | Single Socket SP5 (LGA 6096) AMD EPYC™ 9004 Series Processors CPU TDP 400W |
| Cores | 96/192 |
| System Memory | |
|---|---|
| Memory Capacity | 12 DIMM slots Up to 3TB 3DS ECC Registered RDIMM, DDR5-4800MHz |
| Memory Type | 4800 MT/s ECC DDR5 RDIMM (3DS) Up to 256GB of memory with speeds of up to 4800MHz (1DPC) |
| DIMM Sizes | 16GB, 24GB, 32GB, 40GB, 48GB, 64GB, 80GB, 96GB, 128GB, 192GB, 256GB |
| Memory Voltage | 1.1V |
| Error Detection | Corrects single-bit errors Detects double-bit errors (using ECC memory) |
| On-Board Devices | |
|---|---|
| Chipset | System on Chip |
| Network Controllers | Dual LAN with Broadcom BCM5720 1GBase-T Dual LAN with Broadcom BCM57416 10GBase-T — for BA-SAE35-2LTCV4-T-Ronly |
| Input / Output | |
|---|---|
| LAN | 2x 1GbE RJ45 LAN ports 2x 10GbE RJ45 LAN ports — for BA-SAE35-2LTCV4-T-Ronly 1 RJ45 Dedicated IPMI LAN port |
| USB | 6 USB 3.0 ports (4 USB; 2 via header) |
| Video Output | 1 VGA port |
| Serial Port | 1 COM port (Header) |
| TPM | 1 TPM Header |
| Others | 1 MCIO (PCIe 5.0 x8/SATA3) ports 2 MCIO (PCIe 5.0 x8) ports |
| System BIOS | |
|---|---|
| BIOS Type | AMI 32MB SPI Flash EEPROM |
| BIOS Features | ACPI 6.4 SMBIOS 3.5 or later UEFI 2.8 Plug and Play (PnP) USB Keyboard support |
| Management | |
|---|---|
| Software | SuperDoctor® 5 SPM SUM SSM Watchdog IPMICFG IPMIView for Linux/Windows SMCIPMITool IPMI 2.0 KVM with dedicated LAN |
| PC Health Monitoring | |
|---|---|
| Voltage | VBAT, Memory temperature, CPU temperature, 3.3V standby, +5V standby, +5V, +3.3V, +12V, VRM temperature, CPU thermal trip support, 1.8V standby |
| LED | UID/Remote UID BMC/IPMI Heartbeat LED |
| Other Features | RoT |
| Chassis | |
|---|---|
| Form Factor | 2U Rackmount |
| Dimensions and Weight | |
|---|---|
| Height | 8.89 cm (88 mm) |
| Width | 43.68 cm (437 mm) |
| Depth | 64.77 cm (647 mm) |
| Gross Weight | 52 lbs (23.59 kg) |
| Packaging (W x H x L) | 67.81 cm (678 mm) x 28.95 cm (290 mm) x 87.63 cm (876 mm) |
| Available Color | Black |
| Front Panel | |
|---|---|
| Buttons | Power On/Off button System Reset button |
| LEDs | Power status LED HDD activity LED System Information LED Power Fail LED 2 Network Activity LEDs |
| Expansion Slots | |
|---|---|
| PCI-Express | — 5x PCI-E low-profile slots: 3 PCI-E 5.0 x16 (in x16 slot) 2 PCI-E 5.0 x8 |
| Drive Bays / Storage | |
|---|---|
| Hot-swap | 2x 3.5" fixed drive bays 8x 3.5" hot-swap SAS3/SATA drive bays |
| M.2 | M.2 Interface: 2 SATA/PCI-E 4.0 x4 |
| Peripheral Drives | |
|---|---|
| Optional 1x slim DVD-ROM drive bay Optional 1x COM port tray Optional 2x USB 2.0 ports Optional 2x USB 3.0 ports | |
| Backplane | |
|---|---|
| 8-Port 2U SAS3 12Gbps TQ backplane, support up to 8x 3.5-inch SAS3/SATA3 HDD/SSD | |
| System Cooling | |
|---|---|
| Fans | 3x heavy-duty PWM fans |
| Power Supply | |
|---|---|
| 2x 1000W Redundant Titanium Single Output Power Supplies with PMbus | |
| Dimension (L x W x H) | 336 x 76 x 40 mm |
| Total Output Power and Input | 800W with Input 100 - 127Vac 1000W with Input 200 - 240Vac 1000W with Input 200 - 240Vdc |
| AC Input | 50-60Hz |
| +12V | Max: 66.7A / Min: 0A (100Vac - 127Vac) Max: 83A / Min: 0A (200Vac - 240Vac) Max: 83A / Min: 0A (200Vdc - 240Vdc) |
| +5Vsb | Max: 4A / Min: 0A |
| Power Distributor | PDB-PT825-8824 O/P: 12V/75 +5V Max: 30A +3.3V Max: 24A -12V Max: 0.6A |
| Power Efficiency | 96% |
| Certification | 80 PLUS Titanium Certified |
| Regulatory (Power Supply) | |
|---|---|
| Power Supply Safety / EMC | BSMI CCC CE/EMC FCC class A UL/CB UL/CUL |
| Order Information | ||
|---|---|---|
| Manufacturer SKU | BA-SAE35-2LTCV4-R | |
| System Building | BA-SAE35-2LTCV4-R configured by Happyware as Complete System | |
Happyware BA-SAE35-2LTCV4-R Nitelikleri
| Add-on card form factor: | HH |
|---|---|
| Applications: | Big Data, Cloud Computing, DB Processing & Storage, Data Center Optimized, Database, Database/Storage, Database Processing and Storage, HPC, Networking |
| Backplane: | Yes |
| Backplane Interface: | SAS 1.0, SAS 2.0, SAS 3.0, SATA I, SATA II, SATA III |
| Bluetooth Support: | None |
| CPU Codename: | Genoa |
| CPU Manufacturer: | AMD |
| CPU Socket: | SP5 |
| Card Reader Support: | No |
| Certification: | 80 Plus Titanium |
| Chassis Intrusion: | No |
| Computer group: | Server |
| Design: | Rackmount |
| Front I/O: | LED Indicators |
| Height units: | 2U |
| HotSwap/Fixed Drives: | Yes |
| HotSwap/Fixed Power Supply: | Hot-Swap Power Supply |
| IPMI / BMC: | Yes |
| Lighting: | LED |
| Motherboard Chipset: | System on Chip |
| Number of CPU sockets: | No |
| Number of RAM Pins: | 288 |
| Number of RAM Slots: | N/A |
| Onboard Graphic: | No |
| Onboard LAN: | Yes |
| Onboard Network Speed: | 1 Gb/s |
| PSU Power Wattage: | 1000W |
| Performance Class: | Enterprise-Class, High-End |
| Power Supply Cooler: | No |
| Pre-installed Components: | None |
| Pre-installed Software: | Citrix Hypervisor (formerly XenServer), Oracle Linux, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu, VMware ESXi, Windows Server |
| Product Model: | SAE35-2LTCV4-R |
| Quantity of Cooler: | 3 |
| Quantity of Power Supplies: | 2 |
| RAID Support: | No |
| RAM DIMM Type: | RDIMM |
| RAM ECC: | ECC |
| RAM registered/unregistered: | Registered |
| Redundant power: | Yes |
| Server Fanless: | No |
| Special Features: | LEDs |
| Specific Ports: | M.2 Ports, SAS Ports, SATA Ports, USB Ports, VGA Ports |
| Suitability: | Server |
| Use case: | Cloud Computing, Database Server, File Storage and Sharing, High-Performance Computing (HPC), Networking |
| Wi-Fi Support: | None |
| iGPU Manufacturer: | N/A |
