BA-SXE35HSQ-TFTV4 | Happyware Single Socket Xeon E-2400 4U Server
Başlayan €1.289,15*
KDV artı nakliye masrafları dahil fiyatlar
Happyware BA-SXE35HSQ-TFTV4
Unleash the Power of Customization with Happyware's BA-SXE35HSQ-TFTV4 Barebone Solution
Introducing the BA-SXE35HSQ-TFTV4 from Happyware, a versatile barebone system designed to cater to tech enthusiasts and professionals seeking performance and customization. This product stands out with its exceptional engineering and robust capabilities, ensuring it can adapt to your specific needs. The BA-SXE35HSQ-TFTV4 boasts a sleek, modern design that seamlessly fits into any workspace, while its superior build quality ensures durability and reliability. Powered by the innovation and expertise of Happyware, this barebone offers the flexibility to craft your ideal system configuration, whether for intense gaming, creative projects, or enterprise solutions.
Why Choose Happyware's BA-SXE35HSQ-TFTV4?
Happyware's commitment to quality and customer satisfaction is unmatched. By choosing the BA-SXE35HSQ-TFTV4, you benefit from a product designed by experts who understand the demands of modern technology. Enjoy peace of mind with a system that's engineered for excellence and backed by a leading name in the industry.
With the BA-SXE35HSQ-TFTV4, you're not just buying a product; you're investing in a future-proof solution. Customize your setup with ease, choosing components that match your workload requirements and budget. This barebone acts as a blank canvas, ready for you to create your masterpiece in computing efficiency.
Key Applications:
• Entry-Level Server
• Designed for Small and Medium-sized Business Applications
• Networking
• Database
Ready to power up your business? Don't let performance limitations hold you back—take the leap into next-level technology today. Contact your authorised Happyware reseller now and experience the performance that drives success!
Happyware BA-SXE35HSQ-TFTV4 Teknik Özellikleri
| BA-SXE35HSQ-TFTV4 | Single Intel Xeon E-2400 CPU, 8x 3.5"/2.5" hot-swap drive bays, 3x PCIe (FHFL), 2x 1GbE LAN, 1x 900W Single PSU |
| BA-SXE35HSQ-TFTV4-LN4 | Single Intel Xeon E-2400 CPU, 8x 3.5"/2.5" hot-swap drive bays, 3x PCIe (FHFL), 4x 1GbE LAN, 1x 900W Single PSU |
| BA-SXE35HSQ-TFACV4-R | Single Intel Xeon E-2400 CPU, 8x 3.5"/2.5" hot-swap drive bays, 3x PCIe (FHFL), 2x 1GbE LAN, 2x 1200W redundant PSUs |
| BA-SXE35HSQ-TFACV4-LN4-R | Single Intel Xeon E-2400 CPU, 8x 3.5"/2.5" hot-swap drive bays, 3x PCIe (FHFL), 4x 1GbE LAN, 2x 1200W redundant PSUs |
| Processor | |
|---|---|
| CPU | Single Socket V (LGA-1700) Intel® Xeon® E-2400/Pentium G7400 and G7400T® Processor CPU TDP 95W |
| Cores | 8 cores |
| System Memory | |
|---|---|
| Memory Capacity | 4 DIMM slots Up to 128GB Unbuffered ECC UDIMM, DDR5-4400MHz |
| Memory Type | 4400/4000/3600 MT/s Up to 128GB of memory with speeds of up to 4400MT/s (2DPC) |
| DIMM Sizes | 8GB, 16GB, 32GB |
| Memory Voltage | 1.1V |
| Error Detection | Corrects single-bit errors Detects double-bit errors (using ECC memory) |
| On-Board Devices | |
|---|---|
| Chipset | Intel® C266 |
| SATA | Intel® C266 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10 |
| IPMI | ASPEED AST2600 BMC |
| Graphics | 1 ASPEED AST2600 BMC port |
| Network Controllers | Quad LAN with 1GbE with Intel® I210 — for BA-SXE35HSQ-TFTV4-LN4 and BA-SXE35HSQ-TFACV4-LN4-R skus only Dual LAN with 1GbE with Intel® I210 — for BA-SXE35HSQ-TFTV4 and BA-SXE35HSQ-TFACV4-R skus only |
| Input / Output | |
|---|---|
| SATA | 8 SATA3 (6Gbps) ports via Slimline SAS x8 connector |
| LAN | 4 RJ45 Gigabit Ethernet LAN ports — for BA-SXE35HSQ-TFTV4-LN4 and BA-SXE35HSQ-TFACV4-LN4-R skus only 2 RJ45 Gigabit Ethernet LAN ports — for BA-SXE35HSQ-TFTV4 and BA-SXE35HSQ-TFACV4-R skus only 1 RJ45 Dedicated IPMI LAN port |
| USB | 6 USB 2.0 ports (4 via header; 2 rear) 5 USB 3.2 Gen1 ports (2 via header; 2 rear; 1 type A) |
| Video | 1 VGA D-Sub Connector port |
| Serial Port | 2 COM Ports (1 header; 1 rear) |
| TPM | 1 TPM Header |
| System BIOS | |
|---|---|
| BIOS Type | AMI 32MB AMI UEFI |
| BIOS Features | ACPI 6.4 SMBIOS 3.5 UEFI 2.8 Plug and Play (PnP) PCI FW 3.3 |
| Management | |
|---|---|
| Software | Redfish API, Supermicro Server Manager (SSM), Supermicro Update Manager (SUM), Supermicro SuperDoctor® 5 (SD5), Super Diagnostics Offline (SDO), KVM with dedicated LAN , IPMI 2.0 |
| Power Configurations | ACPI Power Management, Power-on mode control for AC power loss recovery, Power button override mechanism, Wake-On-LAN |
| PC Health Monitoring | |
|---|---|
| Voltage | VBAT, System level control, Supports system management utility, Monitors CPU voltages, Chipset Voltage, Chassis intrusion header, +5V standby, +5V, +3.3V, +12V, Memory Voltages, 7-fan status, +3.3V standby |
| LED | UID/Remote UID CPU / System Overheat LED |
| Temperature | Monitoring for CPU and chassis environment CPU thermal trip support PECI |
| Fan | 7x 4-pin fan headers (up to 7 fans) Fan speed control 7 fans with tachometer monitoring Overheat LED indication |
| Other Features | WOL, UID, M.2 NGFF connector, Control of power-on for recovery from AC power loss, Chassis intrusion header, ACPI power management |
| Security | |
|---|---|
| Hardware | Trusted Platform Module (TPM) 2.0 |
| Chassis | |
|---|---|
| Form Factor | 4U/Full Tower |
| Dimensions and Weight | |
|---|---|
| Height | 45.2cm (452 mm) |
| Width | 17.8cm (178 mm) |
| Depth | 64.7cm (647 mm) |
| Gross Weight | 56 lbs (25.4 kg) |
| Net Weight | 53 lbs (24.04 kg) |
| Packaging (W x H x L) | 62.5cm (625 mm) x 35.6cm (356 mm) x 79.5cm (795 mm) |
| Available Color | Black |
| Front Panel | |
|---|---|
| Buttons | Power On/Off button System Reset button |
| LEDs | Power status LED HDD activity LED 2 Network Activity LEDs Unit Identification (UID) LED Fan Fail/System Over Heat LED |
| Ports | 2x USB 3.0 Ports |
| Expansion Slots | |
|---|---|
| PCI-Express | 1 PCIe 5.0 x16 volle Höhe, volle Länge Steckplätze 2 PCIe 4.0 x4 (in x8-Steckplatz) volle Höhe, volle Länge Steckplätze |
| Storage | |
|---|---|
| Drive Bays | 8x 3.5"/2.5" hot-swap SAS drive bays with SES3 |
| M.2 | M.2 Interface: 2 PCIe 4.0 x4 |
| Backplane | |
|---|---|
| 743 SAS BACKPLANE w/AMI MG9072 |
| Peripheral Drives | |
|---|---|
| 90 degree rotatable drive cage 3x standard 5.25" drive bays |
| System Cooling | |
|---|---|
| Fans | 2x 2800 RPM fans 1x 2700 RPM fans |
| Power Supply | |
|---|---|
| 1x 900W multiple outputs power supply, Gold level — for BA-SXE35HSQ-TFTV4 and BA-SXE35HSQ-TFTV4-LN4 skus only 2x 1200W redundant Power Supplies, Titanium Level — for BA-SXE35HSQ-TFACV4-R and BA-SXE35HSQ-TFACV4-LN4-R skus only | |
| Dimensions (H x W x D) | 190 x 150 x 86 mm 336 x 76 x 40 mm |
| Total Output Power and Input | 900W with Input 100 - 240Vac 1200W mit Input 200 - 240Vac 1000W mit Input 100 - 127Vac 1200W mit Input 200 - 240Vdc |
| AC Input Frequency | 50-60Hz |
| Output Type | 24pin ATX Backplanes (connector) |
| +12V | Max: 25A / Min: 0.1A (100Vac - 240Vac) Max: 25A / Min: 0.1A (100Vac - 120Vac) Max: 100A / Min: 0A (200Vac - 240Vac) Max: 83A / Min: 0A (100Vac - 127Vac) |
| +5Vsb | Max: 4A / Min: 0.02A Max: 4A / Min: 0A |
| Regulatory (Power Supply) | |
|---|---|
| Power Supply Safety / EMC | BSMI CCC CE/EMC FCC class B TUV/CB UL/CUL |
| Order Information | ||
|---|---|---|
| Manufacturer SKU | BA-SXE35HSQ-TFTV4 | |
| System Building | BA-SXE35HSQ-TFTV4 configured by Happyware as Complete System | |
Happyware BA-SXE35HSQ-TFTV4 Nitelikleri
| Add-on card form factor: | FH |
|---|---|
| Applications: | Big Data, Data Center Applications, Data Center Optimized, Database, Database Applications, Networking, Small Business |
| Backplane: | Yes |
| Backplane Interface: | SAS 1.0, SAS 2.0, SAS 3.0 |
| Bluetooth Support: | None |
| CPU Codename: | Alder Lake |
| CPU Manufacturer: | Intel |
| CPU Socket: | 1700 |
| Card Reader Support: | No |
| Certification: | 80 Plus Gold |
| Chassis Intrusion: | Yes |
| Computer group: | Server |
| Design: | Rackmount/Tower |
| Front I/O: | LED Indicators, USB Type-A |
| Height units: | 4U |
| HotSwap/Fixed Drives: | Yes |
| HotSwap/Fixed Power Supply: | Fixed Power Supply |
| IPMI / BMC: | Yes |
| Lighting: | LED |
| Motherboard Chipset: | C266 |
| Number of CPU sockets: | No |
| Number of RAM Pins: | 288 |
| Number of RAM Slots: | N/A |
| Onboard Graphic: | Yes |
| Onboard LAN: | Yes |
| Onboard Network Speed: | 1 Gb/s |
| PSU Power Wattage: | 900W |
| Performance Class: | Enterprise-Class, High-End |
| Power Supply Cooler: | No |
| Pre-installed Components: | None |
| Pre-installed Software: | Oracle Linux, Red Hat Enterprise Linux, Rocky Linux, SUSE Linux Enterprise Server, Ubuntu, VMware ESXi, Windows 11, Windows Server |
| Product Model: | SXE35HSQ-TFTV4 |
| Quantity of Cooler: | 7 |
| Quantity of Power Supplies: | 1 |
| RAID Support: | Yes |
| RAM DIMM Type: | UDIMM |
| RAM ECC: | ECC |
| RAM registered/unregistered: | Unbuffered |
| Redundant power: | No |
| Server Fanless: | No |
| Special Features: | LEDs |
| Specific Ports: | M.2 Ports, SAS Ports, USB Ports, VGA Ports |
| Suitability: | Server |
| Use case: | Database Server, Networking |
| Wi-Fi Support: | None |
| iGPU Manufacturer: | N/A |
