BA-SXS35-TFTV4-T-R | Happyware Single Socket Xeon Scalable 4U Server
Başlayan €2.186,01*
KDV artı nakliye masrafları dahil fiyatlar
Happyware BA-SXS35-TFTV4-T-R
Welcome to the Future of Computing with the Happyware BA-SXS35-TFTV4-T-R Barebone System
Introducing the Happyware BA-SXS35-TFTV4-T-R barebone system is here to redefine your computing experience. Built with precision and designed for performance, this cutting-edge product embodies the perfect blend of technology and innovation. Happyware’s BA-SXS35-TFTV4-T-R is engineered to deliver exceptional efficiency and power, making it the perfect choice for tech enthusiasts and professionals alike. Whether you're upgrading your system or building a new one, this barebone solution offers unparalleled reliability and scalability.
Why Choose BA-SXS35-TFTV4-T-R?
With its sleek design and robust architecture, the BA-SXS35-TFTV4-T-R stands out in the world of computing. Happyware's commitment to quality and craftsmanship ensures that every component meets the highest standards, providing you with an unparalleled computing experience that you can trust.
Choosing the BA-SXS35-TFTV4-T-R means choosing excellence. This barebone system offers a range of compelling features and benefits:
Key Applications:
• Virtualization
• Enterprise Server
• Data Center Optimized
• Database Processing
Don’t miss out on the opportunity to transform your computing setup. Experience the best in performance and innovation with the Happyware BA-SXS35-TFTV4-T-R. Contact us at Happyware now to discuss how it can transform your business operations. Call us today to get started and explore the full potential of this cutting-edge server solution!
Happyware BA-SXS35-TFTV4-T-R Teknik Özellikleri
| Single Intel Xeon Scalable 4th Gen CPU, 8x 3.5" hot-swap drive bays + 2x 5.25 HDD, 5x PCIe (FHFL) + 2x PCIe MCIO connector, 2x 10GbE LAN, 2x 900W redundant PSUs |
| Processor | |
|---|---|
| CPU | Single Socket E (LGA-4677) 4th Gen Intel® Xeon® Scalable processors 350W cTDP |
| Cores | 60 cores |
| System Memory | |
|---|---|
| Memory Capacity | 8 DIMM slots Up to 2TB 3DS ECC RDIMM, DDR5-4800MHz |
| Memory Type | 4800/4400/4000 MT/s ECC DDR5 RDIMM (3DS) Up to 256GB of memory with speeds of up to 4800MT/s (1DPC) |
| DIMM Sizes | 16GB, 32GB, 64GB, 128GB, 256GB RDIMM: 16GB, 32GB, 64GB, 128GB, 256GB |
| Memory Voltage | 1.1V |
| Error Detection | Corrects single-bit errors |
| On-Board Devices | |
|---|---|
| Chipset | Intel® C741 |
| IPMI | ASPEED AST2600 BMC |
| Graphics | ASPEED AST2600 BMC port |
| Network Controllers | Dual LAN with 10GBase-T with Intel® X550 |
| Input / Output | |
|---|---|
| LAN | 2 RJ45 10 Gigabit Ethernet LAN ports 1 RJ45 Dedicated IPMI LAN port |
| USB | 2 USB 2 ports (2 rear) 4 USB 3.2 Gen1 ports (2 rear; 1 type A; 1 via header) |
| Video | 1 VGA D-Sub Connector port |
| Serial Port | 1 COM Port (1 header) |
| DOM | 2 SATA DOM (Disk on Module) power connector support |
| TPM | 1 TPM Header |
| System BIOS | |
|---|---|
| BIOS Type | AMI UEFI |
| BIOS Features | ACPI 6.4 SMBIOS 3.5 or later UEFI 2.8 |
| Management | |
|---|---|
| Software | Redfish API, Supermicro Server Manager (SSM), Supermicro Power Manager (SPM), Supermicro Update Manager (SUM), SuperDoctor® 5, Super Diagnostics Offline , KVM with dedicated LAN , IPMI 2.0 |
| Security | |
|---|---|
| Hardware | Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Features | Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery Supply Chain Security: Remote Attestation Runtime BMC Protections System Lockdown |
| PC Health Monitoring | |
|---|---|
| Voltage | VBAT, System level control, Supports system management utility, Monitors CPU voltages, Chipset Voltage, Chassis intrusion header, 6 -fan status, +5V standby, +5V, +3.3V, +12V, Memory Voltages |
| LED | UID/Remote UID CPU / System Overheat LED |
| Temperature | Monitoring for CPU and chassis environment CPU thermal trip support Thermal Monitor 2 (TM2) support PECI |
| Other Features | WOL, UID, Node Manager Support, M.2 NGFF connector, Control of power-on for recovery from AC power loss, Chassis intrusion detection, ACPI power management |
| Chassis | |
|---|---|
| Form Factor | 4U Rackmount/Tower |
| Dimensions and Weight | |
|---|---|
| Height | 45.2cm (452 mm) |
| Width | 17.8cm (178 mm) |
| Depth | 64.7cm (647 mm) |
| Gross Weight | 64 lbs (29.03 kg) |
| Net Weight | 62 lbs (28.12 kg) |
| Packaging (W x H x L) | 62.5cm (625 mm) x 35.6cm (356 mm) x 76.5cm (795 mm) |
| Available Color | Black |
| Front Panel | |
|---|---|
| Buttons | Power On/Off button System Reset button |
| LEDs | Power status LED HDD activity LED 2 Network Activity LEDs Fan Fail/System Over Heat LED |
| Port | 2x USB 2.0 Ports |
| Expansion Slots | |
|---|---|
| PCI-Express | 2x PCI-E 5.0 x16 full-height, full-length slots 3x PCI-E 5.0 x8 full-height, full-length slots 2x PCI-E 5.0 x8 MCIO connector |
| Drive Bays / Storage | |
|---|---|
| Hot-swap | 8x 3.5" hot-swap SAS/SATA drive bays (4x U.2 Hybrid optional) |
| M.2 | M.2 Interface: 2 PCIe 5.0 x4 |
| Peripheral Drives | |
|---|---|
| 2x 5.25 External-HDD | |
| System Cooling | |
|---|---|
| Fans | 2x hot-swap exhaust fans & air shroud 3x high-performance PWM fans |
| Operating Environment (System) | |
|---|---|
| Operating Temperature Range | 5°C - 35°C (41°F - 95°F) |
| Non-Operating Temperature Range | -40°C - 70°C (-40°F - 158°F) |
| Operating Relative Humidity Range | 8% - 90% (non-condensing) |
| Non Operating Relative Humidity Range | 5% - 95% (non-condensing) |
| Power Supply | |
|---|---|
| 1U 2x 900W Redundant Platinum Super Quiet power supply W/PMbus | |
| Power Efficiency | 94% |
| Total Output Power and Input | 900W with Input 100 - 240Va |
| AC Input Frequency | 50-60Hz |
| Dimensions (L x W x H) | 336 x 76 x 40 mm |
| Output Type | Backplanes (gold finger) |
| +12V | Max: 75A / Min: 1A (100Vac - 240Vac) |
| +5Vsb | Max: 4A / Min: 0A |
| Power Distributor | PDB-PT747-4648 O/P: 12/212 +5V Max: 30A +3.3V Max: 24A -12V Max: 0.6A |
| Certification | 80 PLUS Platinum Level |
| Regulatory (Power Supply) | |
|---|---|
| Power Supply Safety / EMC | BSMI CCC CE/EMC FCC class B TUV/CB UL/CUL |
| Order Information | ||
|---|---|---|
| Manufacturer SKU | BA-SXS35-TFTV4-T-R | |
| System Building | BA-SXS35-TFTV4-T-R configured by Happyware as Complete System | |
Happyware BA-SXS35-TFTV4-T-R Nitelikleri
| Add-on card form factor: | FH, HH |
|---|---|
| Applications: | Application and data serving, Big Data, Data Center Applications, Data Center Optimized, Database, Database Applications, Enterprise Applications, Enterprise Server, Virtualization |
| Backplane: | Yes |
| Backplane Interface: | SAS 1.0, SAS 2.0, SAS 3.0, SATA I, SATA II, SATA III, U.2 NVMe |
| Bluetooth Support: | None |
| CPU Codename: | Sapphire Rapids |
| CPU Manufacturer: | Intel |
| CPU Socket: | 4677 |
| Card Reader Support: | No |
| Certification: | 80 Plus Platinum |
| Chassis Intrusion: | Yes |
| Computer group: | Server |
| Design: | Rackmount/Tower |
| Front I/O: | LED Indicators, USB Type-A |
| Height units: | 4U |
| HotSwap/Fixed Drives: | Yes |
| HotSwap/Fixed Power Supply: | Hot-Swap Power Supply |
| IPMI / BMC: | Yes |
| Lighting: | LED |
| Motherboard Chipset: | C741 |
| Number of CPU sockets: | No |
| Number of RAM Pins: | 288 |
| Number of RAM Slots: | N/A |
| Onboard Graphic: | Yes |
| Onboard LAN: | Yes |
| Onboard Network Speed: | 10 Gb/s |
| PSU Power Wattage: | 900W |
| Performance Class: | Enterprise-Class, Mid-Range |
| Power Supply Cooler: | No |
| Pre-installed Components: | None |
| Pre-installed Software: | Citrix Hypervisor (formerly XenServer), Oracle Linux, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu, VMware ESXi, Windows 10, Windows 11, Windows Server |
| Product Model: | SXS35-TFTV4-T-R |
| Quantity of Cooler: | 5 |
| Quantity of Power Supplies: | 2 |
| RAID Support: | No |
| RAM DIMM Type: | RDIMM |
| RAM ECC: | ECC |
| RAM registered/unregistered: | Registered |
| Redundant power: | Yes |
| Server Fanless: | No |
| Special Features: | LEDs |
| Specific Ports: | M.2 Ports, NVMe Ports, SAS Ports, SATA Ports, U.2 Ports, USB Ports, VGA Ports |
| Suitability: | Server |
| Use case: | Data Analytics, Database Server, Virtualization |
| Wi-Fi Support: | None |
| iGPU Manufacturer: | N/A |
