Supermicro AS-2015SV-WTNRT

High-Performance 2U Rack Server Barebone featuring AMD EPYC Siena compute and 12-bay hot-swap storage with the AS-2015SV-WTNRT Supermicro

The AS-2015SV-WTNRT Supermicro is a 2U single-socket platform built around AMD EPYC 8004 (Siena/SP6), targeting virtualization and general-purpose enterprise compute where core density, power efficiency, and predictable expansion are required. Its DDR5 ECC RDIMM design with 6 DIMM slots prioritizes memory integrity and bandwidth for consolidation, while keeping the platform balanced for edge and branch deployments.

For I/O, the AS-2015SV-WTNRT Supermicro integrates PCIe 5.0 expansion with GPU-capable full-height, full-length slots and additional low-profile lanes for NICs or storage controllers. Storage architecture is optimized for capacity and serviceability through 12 front hot-swap bays, with configuration flexibility for SATA capacity, optional PCIe 5.0 NVMe tiering, or SAS backplanes where controller and cabling dictate. Dual M.2 NVMe boot support enables clean separation of OS from data planes.

Why Choose the AS-2015SV-WTNRT Supermicro?

The AS-2015SV-WTNRT Supermicro delivers a disciplined density-to-performance profile: a single-socket EPYC Siena design reduces platform complexity while preserving PCIe 5.0 bandwidth and a 12-bay serviceable storage front. Redundant Titanium-rated power, IPMI-managed operations, and security foundations such as Silicon Root of Trust and TPM 2.0 readiness support reliable scale-out deployment across enterprise and edge footprints.

Supermicro engineering emphasizes modular, standards-aligned server building blocks, combining field-friendly serviceability with validation for continuous operation. The platform’s management stack and secure firmware posture are designed to align with modern data centre governance and lifecycle automation.

Key Applications:

  • Virtualization and VDI infrastructure
  • General-purpose enterprise compute
  • Edge cloud services
  • Firewall and security appliances
  • Capacity-focused storage nodes

At Happyware Turkiye you benefit from streamlined B2B procurement for the AS-2015SV-WTNRT Supermicro, including configuration guidance for PCIe 5.0 expansion and storage tiering, responsive project fulfilment, and professional after-sales coordination for enterprise rollouts.

Supermicro AS-2015SV-WTNRT Teknik Özellikleri

SKU Genel Bakış
2015SV-WTNRT Tek AMD EPYC 8004 İşlemci, 12x Hot-Swap Disk Yuvaları, 4x PCIe, 2x 800W Yedekli PSU
İşlemci
CPU Tek İşlemci
AMD EPYC 8004
AMD EPYC Serisi İşlemciler
4th Nesil, Siena
Çekirdek Sayısı64 adede kadar çekirdek
İş Parçacığı128 adede kadar iş parçacığı
TDP 225W'a kadar cTDP desteği
Not
Soket
Soket Tipi ve Adedi 1x sTR5 (LGA 4844)
Not
Sistem Belleği
Bellek 6x DIMM yuvası ECC DDR5 RDIMM, 768GB'a kadar RAM
Bellek Voltajı1.1V
RAM Yapılandırması Dual-Rank x8, Dual-Rank x4, Single-Rank x8
Not
Depolama ve Denetleyici Yapılandırması
Sürücü Yuvaları 12x 3.5" SATA Çıkarılabilir Disk Yuvası
M.2 Yuvaları 2x M.2 yuva , Arayüz: NVME,PCIe Gen 3 , Form Faktörü: M.2 2280/M.2 22110 , M-Key
RAIDRAID Desteği
Not
Genişletme Yuvaları
PCI-Express (PCIe) Yapılandırması 2x PCIe 5.0 x16 Full-Height Full-Length (Standard) yuvası
2x PCIe 5.0 x8 Low-Profile yuvası
GPU
Entegre GPU Evet, ASpeed
Not
LAN 2x 10 Gbps RJ45 üzerinden BCM57416
IPMI / BMC Desteği Evet
Not
Anakart Üzerindeki Bileşenler
Yonga Seti ModeliSystem-on-Chip (SoC)
G/Ç Bağlantı Noktaları
USB 4x USB 3.0 Type-A (harici)
Video 1x VGA
Ön PanelLED Indicators
Not
Sistem Soğutması
Dahil / Desteklenen Fanlar Evet
Soğutucu Adedi3
Hava Körüğü Evet
Hava Kılavuzu Adedi1
Sıvı Soğutmalı Hayır
Not
Güç Kaynağı
2x 800W Redundant Yedekli PSU Güç Kaynakları 80 Plus Titanium Seviyesi
Güç Kaynağı SoğutucusuNo
Not
Yönetim / İşletim Sistemi / Sertifikalar
İşletim Sistemi Uyumluluğu / Desteklenen Windows Server
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
Oracle Linux
VMware ESXi
Yönetim YazılımıSuperCloud Composer®, Supermicro SuperDoctor® 5 (SD5), Supermicro Thin-Agent Service (TAS), SuperServer Automation Assistant (SAA) New!, Supermicro Update Manager (SUM), Supermicro Server Manager (SSM), Super Diagnostics Offline (SDO)
BIOS Bilgisi
BIOS AMI UEFI , ACPI 6.4 support, SMBIOS 3.5 support, USB Keyboard support, UEFI BIOS, Plug and Play (PnP)
Uyumluluk Sertifikaları 80 Plus Titanium
Not
Diğer Özellikler
Form Faktörü 2U Rack
Düğüm Sayısı 1 Düğüm
Donanım Tabanlı Güvenlik ÖzellikleriTrusted Platform Module (TPM) 2.0, Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Önceden Yüklenmiş BileşenlerNone
UygunlukServer
Performans SınıfıEnterprise-Class
Kullanım AlanıFirewall Application, Data Center Applications, Data Center Optimized, Big Data, Database Processing and Storage, Database, Edge Computing, Virtualization
Genişlik437 mm
Yükseklik89 mm
Derinlik650 mm
Ağırlık26.3 kg
Mevcut RenkBlack
Not

Supermicro AS-2015SV-WTNRT Nitelikleri

Anakart Yonga Seti: System-on-Chip (SoC)
Belgelendirme: 80 Plus Titanium
Belirli Bağlantı Noktaları: USB 3.0 Type-A
Bellek ECC Desteği: ECC
Bellek kayıtlı/kayıtsız: Registered
Dahili Ağ Hızı: 10 Gbps
Dahili Grafik: Yes
Dahili LAN: 2
Dahili M.2: x2 M-Key (M.2 22110, M.2 2280) (NVME, PCIe Gen 3) 0
Düğüm başına GPU sayısı: 0
Düğüm sayısı: 1
Eklenti kartı form faktörü: Full-Height Full-Length (Standard), Low-Profile
Eklenti kartı sayısı: 4
Entegre GPU Üreticisi: ASpeed
Güç Kaynağı Sayısı: 2
Güç Kaynağı Soğutucu: No
Güç kaynağı Watt Değeri: 800W
HDD form faktörü: 3.5"
HotSwap/Sabit Güç Kaynağı: Hot-Swap
IPMI / BMC Yönetimi: Yes
Maksimum Bellek: 768GB
Performans Sınıfı: Enterprise-Class
RAID Desteği: No
RAM DIMM Türü: RDIMM
Sabit disk yuva sayısı: 12
Soğutucu Sayısı: 3
Tasarım: Rack
Uygulamalar: Big Data, Data Center Applications, Data Center Optimized, Database, Database Processing and Storage, Edge Computing, Firewall Application, Virtualization
Uygunluk: Server
Yedekli güç kaynağı: Yes
Yükseklik birimleri: 2U
Ön Giriş/Çıkış: LED Indicators
Önceden Kurulmuş Bileşenler: None
Önceden Yüklenmiş Yazılım: Oracle Linux, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi, Windows Server
Ürün Modeli: 2015SV-WTNRT
İşlemci Kod Adı: Siena
İşlemci Soketi: sTR5 (LGA 4844)
İşlemci Türü: EPYC 8004
İşlemci soket sayısı: No
İşlemci Üreticisi: AMD
Şasi Girişi Algılama: No
