Supermicro SYS-421GE-TNRT
Supercharge Your GPU Performance with the Supermicro SYS-421GE-TNRT GPU Barebone System
Introducing the SYS-421GE-TNRT, an exceptional barebone system meticulously crafted by the industry leader, Supermicro. Designed for those who demand unparalleled performance and reliability, this powerhouse is ideal for professionals and enterprises seeking to push the boundaries of computing power. The Supermicro SYS-421GE-TNRT offers an unparalleled 4U dual-root system, designed to accommodate up to 10 GPUs, making it the ideal choice for AI, deep learning, and data-driven enterprises. With support for NVIDIA’s Ada Generation GPUs and PCIe 5.0, it offers the next level of performance. The system supports up to 8TB of high-speed DDR5 memory, ensuring seamless scalability and support for the most demanding workloads.
Why Choose the Supermicro SYS-421GE-TNRT?
Engineered to perfection, the SYS-421GE-TNRT offers a robust foundation for building a high-performance server. Whether you're managing demanding applications or handling massive data loads, trust in Supermicro's legacy of excellence and innovation. With up to 10 double-width or single-width GPUs, the Supermicro SYS-421GE-TNRT is engineered to deliver cutting-edge performance in a compact, flexible configuration. Dual PCIe 5.0 x16 switches and NVLink® bridges (optional) ensure a high-speed, low-latency interconnect for the most intensive GPU tasks. This system is future-proofed for next-gen workloads, giving enterprises the scalability they need without compromise. Whether you're processing large datasets, running AI models, or powering complex simulations, the SYS-421GE-TNRT ensures maximum efficiency.
Backed by Supermicro’s commitment to quality, the SYS-421GE-TNRT boasts 8 hot-swappable drive bays, redundant 2700W power supplies, and optimized cooling for high-performance operations. It stands out as a go-to choice for businesses looking to stay ahead of the curve in the GPU-powered computing space.
Key Applications:
• High Performance Computing
• VDI
• AI/Deep Learning Training
• Media/Video Streaming
• Cloud Gaming
• Animation and Modeling
• Design & Visualization
• 3D Rendering
• Diagnostic Imaging
Empower your enterprise's infrastructure with a solution that not only meets today's technological demands but prepares you for future advancements. Dive into a world where performance knows no boundaries with the Supermicro SYS-421GE-TNRT. Contact Happyware today to discover how we can elevate your enterprise's capabilities and infrastructure with this cutting-edge solution.
Supermicro SYS-421GE-TNRT Teknik Özellikleri
Dual Intel Xeon Scalable 5th Gen CPU, 16x 2.5" hot-swap drive bays, 13x PCIe Gen5 (FHFL), 2x 10GbE LAN, 4x 2700W redundant PSUs |
Processor/Chipset | |
---|---|
CPU | Dual Socket E (LGA-4677) 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors |
Cores | Up to 64C/128T; Up to 320MB Cache per CPU |
Note | Supports up to 350W TDP CPUs (Air Cooled) Supports up to 385W TDP CPUs (Liquid Cooled) |
GPU | |
---|---|
Max GPU Count | Up to 10 double-width or 10 single-width GPUs |
Supported GPU | NVIDIA PCIe: H100, L40, RTX A4000, RTX 6000 Ada Generation, L40S, A100, A10 Intel PCIe: Data Center GPU Max 1100 |
CPU-GPU Interconnect | PCIe 5.0 x16 Switch Dual-Root |
GPU-GPU Interconnect | NVIDIA® NVLink® Bridge (optional), Intel® Xe Link Bridges |
System Memory | |
---|---|
Memory | Slot Count: 32 DIMM slots Max Memory (1DPC): Up to 4TB 5600MT/s ECC RDIMM Max Memory (2DPC): Up to 8TB 4400MT/s ECC DDR5 RDIMM |
Memory Voltage | 1.1V |
On-Board Devices | |
---|---|
Chipset | Intel® C741 |
Network Connectivity | 2 RJ45 10GbE with Intel® X710-AT2 |
NVMe | - |
Input / Output | |
---|---|
Video | 1 VGA port |
System BIOS | |
---|---|
BIOS Type | AMI 32MB SPI Flash EEPROM |
Management | |
---|---|
Software | SuperCloud Composer Supermicro Server Manager (SSM) Supermicro Update Manager (SUM) Supermicro SuperDoctor® 5 (SD5) Super Diagnostics Offline (SDO) Supermicro Thin-Agent Service (TAS) SuperServer Automation Assistant (SAA) New! |
Power Configurations | Power-on mode for AC power recovery ACPI Power Management |
Security | |
---|---|
Hardware | Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
Features | Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery Supply Chain Security: Remote Attestation Runtime BMC Protections System Lockdown |
PC Health Monitoring | |
---|---|
CPU | Monitors for CPU Cores, Chipset Voltages, Memory 8+4 Phase-switching voltage regulator |
FAN | Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors |
Temperature | Monitoring for CPU and chassis environment Thermal Control for fan connectors |
Chassis | |
---|---|
Form Factor | 4U Rackmount |
Model | CSE-418G2TS-R5K40P |
Dimensions and Weight | |
---|---|
Height | 17.8cm (178 mm) |
Width | 43.7cm (437 mm) |
Depth | 73.7cm (737 mm) |
Package | 67.48cm (H) x 68.58cm (W) x 104.14cm (D) |
Weight | Gross Weight: 100 lbs (45.3 kg) Net Weight: 65.5 lbs (29.7 kg) |
Available Color | Black Front & Silver Body |
Front Panel | |
---|---|
LEDs | Hard drive activity LED Network activity LEDs Power status LED System Overheat & Power Fail LED |
Buttons | Power On/Off button System Reset button |
Expansion Slots | |
---|---|
PCI-Express (PCI-E) Configuration | Default 13 PCIe 5.0 x16 FHFL slots |
Storage | |
---|---|
Drive Bays | Default: Total 16 bays 8 front hot-swap 2.5" NVMe drive bays 8 front hot-swap 2.5" SATA drive bays Option A: Total 24 bays 8 front hot-swap 2.5" NVMe drive bays 8 front hot-swap 2.5" NVMe* drive bays 8 front hot-swap 2.5" SATA drive bays |
M.2 | 2 M.2 NVMe slots (M-key) |
System Cooling | |
---|---|
Fans | 8 heavy duty fans with optimal fan speed control |
Liquid Cooling | Direct to Chip (D2C) Cold Plate (optional) |
Power Supply | |
---|---|
4x 2700W Redundant Titanium Level (96%) power supplies | |
Dimension (W x H x L) | 73.5 x 40 x 203 mm |
AC Input | 2700W: 200-240Vac / 50-60Hz 2700W: 240-240Vdc / 50-60Hz (for CQC only) |
+12V | Max: 225A / Min: 0A (200Vac-240Vac) Max: 225A / Min: 0A (240Vdc-240Vdc) |
12Vsb | Max: 4A / Min: 0A |
Output Type | Backplanes (gold finger) |
Operating Environment / Compliant | ||
---|---|---|
Environmental Spec. | Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
Order Information | ||
---|---|---|
Manufacturer SKU | SYS-421GE-TNRT | |
System Building | SYS-421GE-TNRT configured by Supermicro as Complete System |
Supermicro SYS-421GE-TNRT Nitelikleri
Add-on card form factor: | FH, HH |
---|---|
Applications: | AI / Deep Learning, AI Inference and Machine Learning, Cloud Computing, HPC, ML training, Model analysis, Visual Computing |
Backplane: | Yes |
Backplane Interface: | SATA I, SATA II, SATA III, U.2 NVMe |
Bluetooth Support: | None |
CPU Codename: | Emerald Rapids, Sapphire Rapids |
CPU Manufacturer: | Intel |
CPU Socket: | 4677 |
Card Reader Support: | No |
Certification: | 80 Plus Titanium |
Chassis Intrusion: | No |
Computer group: | Server |
Design: | Rackmount |
Front I/O: | LED Indicators |
GPU quantity per node: | 10 |
Height units: | 4U |
HotSwap/Fixed Drives: | Yes |
HotSwap/Fixed Power Supply: | Hot-Swap Power Supply |
IPMI / BMC: | Yes |
Lighting: | LED |
Motherboard Chipset: | C741 |
Number of CPU sockets: | No |
Number of RAM Pins: | 288 |
Number of RAM Slots: | N/A |
Onboard Controller: | X710-AT2 |
Onboard Graphic: | No |
Onboard LAN: | Yes |
Onboard Network Speed: | 10 Gb/s |
PSU Power Wattage: | 2700W |
Performance Class: | Enterprise-Class, High-End |
Power Supply Cooler: | No |
Pre-installed Components: | None |
Pre-installed Software: | Windows 10, Windows 11, Windows Server |
Product Model: | 421GE-TNRT |
Quantity of Cooler: | 8 |
Quantity of Power Supplies: | 4 |
RAID Support: | No |
RAM DIMM Type: | RDIMM |
RAM ECC: | ECC |
RAM registered/unregistered: | Registered |
Redundant power: | Yes |
Server Fanless: | No |
Special Features: | LEDs |
Specific Ports: | M.2 Ports, NVMe Ports, SATA Ports, U.2 Ports, USB Ports, VGA Ports |
Suitability: | Server |
Use case: | Cloud Computing, Deep Learning - Machine Learning, High-Performance Computing (HPC), Media Streaming |
Wi-Fi Support: | None |
iGPU Manufacturer: | N/A |
