G293-Z43-AAP1 | Gigabyte Dual Socket Epyc 9004 2U Server
Ürün numarası: TR9B2000-412903
|
Üretici numarası: 6NG293Z43DR000AAP1
Başlayan €13.104,68*
KDV artı nakliye masrafları dahil fiyatlar
Gigabyte G293-Z43-AAP1
Unleash Unprecedented Performance with the Gigabyte G293-Z43-AAP1 Barebone System
Introducing the Gigabyte G293-Z43-AAP1, a high-performance server designed for the most demanding HPC and AI workloads. With support for AMD EPYC™ 9004 Series processors, up to 16 x PCIe Gen5 GPUs, and cutting-edge PCIe switches, this 2U DP server delivers extreme computational power and scalability. Whether for AI training, machine learning, or large-scale simulations, the G293-Z43-AAP1 is engineered to meet the evolving needs of enterprises at the forefront of innovation.
Why Choose the Gigabyte G293-Z43-AAP1?
The G293-Z43-AAP1 is a powerhouse that excels in AI acceleration and high-performance computing. It supports dual AMD EPYC™ 9004 processors, providing superior parallel processing and efficiency for complex workloads. With PCIe Gen5 technology, it offers ultra-fast data throughput, enabling seamless GPU scaling and rapid data access for AI-driven tasks.
Designed with a flexible architecture and future-proof scalability, the G293-Z43-AAP1 ensures your infrastructure grows with your business needs. Whether you're running AI models, data analytics, or virtualized applications, this server provides the reliability and performance needed to stay ahead of the competition.
Key Applications:
• AI / AI Inference
• Visual Computing
Transform your AI and HPC capabilities with the Gigabyte G293-Z43-AAP1. Call Happyware today to learn how this server can accelerate your business operations. Alternatively, register your company as a partner with Happyware for exclusive benefits and priority support. Don’t miss the opportunity to power your enterprise with next-gen server technology!
Gigabyte G293-Z43-AAP1 Teknik Özellikleri
| Dual AMD EPYC 9004 Series CPU, 8x 2.5" hot-swap drive bays, 16x PCIe (FHFL) for GPUs + 2x PCIe (LP), 2x 3000W redundant PSUs |
| Dimensions (WxHxD, mm) | 2U 448 x 87.5 x 800 | |
| Motherboard | MS43-G20 | |
| CPU | AMD EPYC™ 9004 series processors Dual processor, 5nm technology Up to 32-core, 64 threads per processor CPU TDP up to 210W cTDP 240W supported at ambient 30°C Note: If only 1 CPU is installed, some PCI-E or memory functions might be unavailable | |
| Socket | 2 x LGA 6096 Socket SP5 | |
| Chipset | System on Chip | |
| Memory | 24 x DIMM slots DDR5 memory supported only 12-Channel memory architecture RDIMM modules up to 96GB supported 3DS RDIMM modules up to 256GB supported Memory speed: Up to 4800 MHz | |
| LAN | Rear side: 2 x 10Gb/s BASE-T LAN ports (1 x Broadcom® BCM57416) Support NCSI function 1 x 10/100/1000 management LAN | |
| Video | Integrated in Aspeed® AST2600 2D Video Graphic Adapter with PCIe bus interface 1920x1200@60Hz 32bpp, DDR4 SDRAM | |
| Storage | Front side: 4 x 2.5" Gen5 NVMe/SATA/SAS hot-swappable bays 4 x 2.5" SATA/SAS hot-swappable bays - (NVMe from CPU_1, SATA from CPU_1) SAS card is required for SAS devices support | |
| SAS | Depends on Add-on SAS card | |
| RAID | N/A | |
| Expansion Slots | Riser Card CRSG742 x 2 - 8 x PCIe x16 (Gen5 x16) FHFL slots, from PEX89088, for GPUs Riser Card CRSG743 x 2 - 8 x PCIe x16 (Gen5 x16) FHFL slots, from PEX89088, for GPUs Riser Card CRSG01F x 2 - 2 x PCIe x16 (Gen5 x16) low-profile slots, from CPU_0 - Maximum limitation of GPU card: 285mm (L) x 111.5mm (W) x 39.5mm (H) - System is validated for population with a uniform GPU model - Support is not provided for mixed GPU populations | |
| Internal I/O | 1 x TPM header | |
| Front I/O | 1 x Power button with LED 1 x ID button with LED 2 x LAN activity LEDs 1 x HDD activity LED 1 x System status LED 1 x Reset button | |
| Rear I/O | 2 x USB 3.2 Gen1 1 x VGA 2 x RJ45 1 x MLAN 1 x Power button with LED 1 x ID button with LED 1 x Reset button 1 x NMI button 1 x System status LED | |
| Backplane I/O | Speed and bandwidth: PCIe Gen5 x4 or SATA 6Gb/s or SAS 12Gb/s | |
| TPM | 1 x TPM header with SPI interface Optional TPM2.0 kit: CTM010 | |
| Power Supply | Dual 3000W (240V) 80 PLUS Titanium redundant power supply AC Input: - 100-127V~/ 15.5A, 50-60Hz - 200-220V~/ 15.5A, 50-60Hz - 220-240V~/ 15.5A, 50-60Hz DC Input: - 240Vdc/ 15.5A DC Output: - Max 1000W/ 100-127V~ + 12.2V/ 81A + 12Vsb/ 3A - Max 2600W/ 200-220V~ + 12.2V/ 213A + 12Vsb/ 3A - Max 3000W/ 220-240V~ or 240Vdc Input + 12.2V/ 245A + 12Vsb/ 3A Note: The system power supply requires C19 type power cord | |
| System Management | Aspeed® AST2600 management controller GIGABYTE Management Console (AMI MegaRAC SP-X) web interface Dashboard HTML5 KVM Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.) Sensor Reading History Data FRU Information SEL Log in Linear Storage / Circular Storage Policy Hardware Inventory Fan Profile System Firewall Power Consumption Power Control Advanced power capping LDAP / AD / RADIUS Support Backup & Restore Configuration Remote BIOS/BMC/CPLD Update Event Log Filter User Management Media Redirection Settings PAM Order Settings SSL Settings SMTP Settings | |
| OS Compatibility | Windows Server 2019 or later Windows Server 2022 or later Red Hat Enterprise Linux 8.6 (x64) or later Red Hat Enterprise Linux 8.7 (x64) or later Red Hat Enterprise Linux 8.8 (x64) or later Red Hat Enterprise Linux 9.0 (x64) or later Red Hat Enterprise Linux 9.1 (x64) or later Red Hat Enterprise Linux 9.2 (x64) or later SUSE Linux Enterprise Server 15 SP4 (x64) or later SUSE Linux Enterprise Server 15 SP5 (x64) or later Ubuntu 20.04.5 LTS (x64) or later Ubuntu 20.04.6 LTS (x64) or later Ubuntu 22.04 LTS (x64) or later Ubuntu 22.04.1 LTS (x64) or later Ubuntu 22.04.2 LTS (x64) or later Ubuntu 22.04.3 LTS (x64) or later VMware ESXi 7.0 Update 3i or later VMware ESXi 8.0 or later VMware ESXi 8.0 Update 1 or later Citrix Hypervisor 8.2 LTSR CU1 or later | |
| System Fans | 8 x 80x80x38mm (18,300rpm) | |
| Operating Properties | Operating temperature: 10°C to 35°C Operating humidity: 8%-80% (non-condensing) Non-operating temperature: -40°C to 60°C Non-operating humidity: 20%-95% (non-condensing) | |
| Packaging Dimensions | 1133 x 724 x 261 mm | |
| Packaging Content | 1 x G293-Z43 2 x CPU heatsinks 1 x L-shape Rail kit | |
| Part Numbers | - Barebone package: 6NG293Z43DR000AAP1* - Motherboard: 9MZ43G20UR-000 - L-shape Rail kit: 25HB2-A86102-K0R - CPU heatsink: 25ST1-243105-A0R/25ST1-553202-A0R - Backplane board - CBPG086: 9CBPG086NR-00 - Fan module: 25ST2-88382R-S1R - Riser card - CRSG01F: 9CRSG01FNR-00 - Riser card - CRSG742: 9CRSG742NR-00 - Riser card - CRSG743: 9CRSG743NR-00 - Power supply: 25EP0-230005-G1S | |
| Optional parts | - C19 power cord 125V/15A (US): 25CP1-018000-Q0R - C19 power cord 250V/16A (EU): 25CP3-01830H-Q0R - RMA packaging: 6NG293Z43SR-RMA-A100 | |
| Order Information | ||
| Manufacturer SKU | G293-Z43 (6NG293Z43DR000AAP1) | |
| System Building | G293-Z43 (6NG293Z43DR000AAP1) can be configured individually | |
Gigabyte G293-Z43-AAP1 Nitelikleri
| Add-on card form factor: | FH, HH |
|---|---|
| Applications: | AI / Deep Learning, AI Inference and Machine Learning, AI inferencing, Enterprise Server, GPU server, HPC, High End Enterprise Server, High Performance Computing, Virtualization, Visual Computing |
| Backplane: | Yes |
| Backplane Interface: | PCIe Gen 5, SAS 1.0, SAS 2.0, SAS 3.0, SATA I, SATA II, SATA III, U.2 NVMe |
| Bluetooth Support: | None |
| CPU Codename: | Genoa |
| CPU Manufacturer: | AMD |
| CPU Socket: | LGA 6096 |
| Card Reader Support: | No |
| Certification: | 80 Plus Titanium |
| Chassis Intrusion: | No |
| Computer group: | Server |
| Design: | Rackmount |
| Front I/O: | LED Indicators |
| GPU quantity per node: | 16 |
| Height units: | 2U |
| HotSwap/Fixed Drives: | Yes |
| HotSwap/Fixed Power Supply: | Hot-Swap Power Supply |
| IPMI / BMC: | Yes |
| Lighting: | LED |
| Motherboard Chipset: | System on Chip |
| Number of CPU sockets: | No |
| Number of RAM Slots: | N/A |
| Onboard Controller: | Broadcom BCM57416 |
| Onboard Graphic: | Yes |
| Onboard LAN: | Yes |
| Onboard Network Speed: | 10 Gb/s |
| PSU Power Wattage: | 3000W |
| Performance Class: | Enterprise-Class, High-End |
| Power Supply Cooler: | No |
| Pre-installed Components: | None |
| Pre-installed Software: | Citrix Hypervisor (formerly XenServer), Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu, VMware ESXi, VMware vCenter, Windows Server |
| Product Model: | G293-Z43-AAP1 |
| Product Version: | Rev-1.x |
| Quantity of Cooler: | 8 |
| Quantity of Power Supplies: | 2 |
| RAID Support: | Yes |
| RAM DIMM Type: | RDIMM |
| RAM ECC: | ECC |
| RAM registered/unregistered: | Registered |
| Redundant power: | Yes |
| Server Fanless: | No |
| Special Features: | LEDs, Suitable for continuous operation |
| Specific Ports: | NVMe Ports, SAS Ports, SATA Ports, U.2 Ports, USB Ports, VGA Ports |
| Suitability: | Server |
| Use case: | Deep Learning - Machine Learning, GPGPU, High-Performance Computing (HPC), Virtualization, Visual Computing |
| Wi-Fi Support: | None |
| iGPU Manufacturer: | AMD |
