G493-ZB1-AAP1 | Gigabyte Dual Socket Epyc 9004 4U Server
Ürün numarası: TR9B3288-320222
|
Üretici numarası: 6NG493ZB1DR000AAP1
Başlayan €16.283,41*
KDV artı nakliye masrafları dahil fiyatlar
Gigabyte G493-ZB1-AAP1
Unleash Powerful Performance with the Gigabyte G493-ZB1-AAP1 HPC/AI Server Barebone System
The Gigabyte G493-ZB1-AAP1 is built to meet the diverse and evolving needs of modern enterprises. Combining industry-leading hardware with scalable infrastructure, this server empowers businesses to tackle demanding applications across a wide range of industries. From accelerating AI innovations to processing complex workloads, it provides a solid foundation for both current and future business needs. Its advanced capabilities ensure your enterprise remains at the forefront of technology, offering dependable performance while maintaining the flexibility needed to scale as your operations grow.
Why Choose the Gigabyte G493-ZB1-AAP1?
The Gigabyte G493-ZB1-AAP1 stands out in the market for its combination of advanced features and enterprise-grade reliability. With dual AMD EPYC™ 9005/9004 processors, this server supports demanding AI/ML tasks, computational simulations, and data-driven workloads without compromising on efficiency. Its 4U design and 10 x PCIe Gen5 GPU slots with switches ensure that your business is ready for the most demanding processing environments.
Equipped with redundant power supplies and enhanced cooling solutions, the G493-ZB1-AAP1 delivers uninterrupted performance under the most intense workloads. Whether you're focused on AI model training, high-performance computing, or deep learning, this server provides the backbone to future-proof your business.
Key Applications:
• AI / AI Training / AI Inference
• High performance Computing
• Visual Computing
Take your enterprise to the next level with the Gigabyte G493-ZB1-AAP1. Call us now or register your company as a partner with Happyware for exclusive benefits and dedicated support. Don’t miss the opportunity to unlock the full potential of your operations with this cutting-edge solution.
Gigabyte G493-ZB1-AAP1 Teknik Özellikleri
| Dual AMD EPYC 9004 Series CPU, 12x 2.5" hot-swap drive bays, 10x PCIe (FHFL) for GPUs + 2x PCIe (LP), 4x 3000W redundant PSUs |
| Dimensions (WxHxD, mm) | 4U 448 x 176 x 880 | |
| Motherboard | MZB3-G41 | |
| CPU | AMD EPYC™ 9004 Series processors AMD EPYC™ 9004 Series processors with AMD 3D V-Cache™ Technology Dual processor, 5nm technology *Up to 128-core, 256 threads per processor cTDP up to 300W at ambient 35°C *cTDP supported up to 400W under limited thermal conditions. Note: If only 1 CPU is installed, some PCI-E or memory functions might be unavailable | |
| Socket | 2 x LGA 6096 Socket SP5 | |
| Chipset | System on Chip | |
| Memory | 48 x DIMM slots DDR5 memory supported only 12-Channel memory architecture RDIMM modules up to 96GB supported 3DS RDIMM modules up to 256GB supported Memory speed: Up to 4800 MHz (1DPC), 3600 MHz (2DPC) | |
| LAN | Front side: 2 x 1Gb/s BASE-T LAN ports (1 x Intel® I350-AM2) NCSI function supported 1 x 10/100/1000 management LAN | |
| Video | Integrated in Aspeed® AST2600 2D Video Graphic Adapter with PCIe bus interface 1920x1200@60Hz 32bpp, DDR4 SDRAM | |
| Storage | Front side: 8 x 2.5" Gen5 NVMe/SATA/SAS hot-swappable bays 4 x 2.5" SATA/SAS hot-swappable bays - (2 x NVMe from CPU_0, 2 x NVMe from CPU_1, 2 x NVMe from PEX89104_0, 2 x NVMe from PEX89104_1) - (8 x SATA from CPU_0, 8 x SATA from CPU_1) SAS card is required for SAS devices support | |
| SAS | Depends on Add-on SAS card | |
| RAID | N/A | |
| Expansion Slots | 5 x PCIe x16 (Gen5 x16) FHFL slots, from PEX89104_0, for GPUs 5 x PCIe x16 (Gen5 x16) FHFL slots, from PEX89104_1, for GPUs 1 x PCIe x16 (Gen5 x16) low-profile slot on front side, from CPU_0 1 x PCIe x16 (Gen5 x16) low-profile slot on front side, from CPU_1 - System is validated for population with a uniform GPU model - Support is not provided for mixed GPU populations 1 x M.2 slot: - M-key - PCIe Gen3 x4, from CPU_0 - Supports 2280/22110 cards 1 x M.2 slot: - M-key - PCIe Gen3 x4, from CPU_1 - Supports 2280/22110 cards | |
| Internal I/O | 2 x M.2 slots 1 x TPM header | |
| Front I/O | 2 x USB 3.2 Gen1 1 x VGA 2 x RJ45 1 x MLAN 1 x Power button with LED 1 x ID button with LED 1 x Reset button 1 x NMI button 1 x System status LED 1 x HDD access LED | |
| Rear I/O | N/A | |
| Backplane I/O | Speed and bandwidth: PCIe Gen5 x4 or SATA 6Gb/s or SAS 12Gb/s | |
| TPM | 1 x TPM header with SPI interface Optional TPM2.0 kit: CTM010 | |
| Power Supply | 3+1 3000W (240V) 80 PLUS Titanium redundant power supplies AC Input: - 100-127V~/ 15.5A, 50-60Hz - 200-220V~/ 15.5A, 50-60Hz - 220-240V~/ 15.5A, 50-60Hz DC Input: - 240Vdc/ 15.5A DC Output: - Max 1000W/ 100-127V~ + 12.2V/ 81A + 12Vsb/ 3A - Max 2600W/ 200-220V~ + 12.2V/ 213A + 12Vsb/ 3A - Max 3000W/ 220-240V~ + 12.2V/ 240A + 12Vsb/ 3A Note: The system power supply requires C19 type power cord | |
| System Management | Aspeed® AST2600 management controller GIGABYTE Management Console (AMI MegaRAC SP-X) web interface Dashboard HTML5 KVM Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.) Sensor Reading History Data FRU Information SEL Log in Linear Storage / Circular Storage Policy Hardware Inventory Fan Profile System Firewall Power Consumption Power Control Advanced power capping LDAP / AD / RADIUS Support Backup & Restore Configuration Remote BIOS/BMC/CPLD Update Event Log Filter User Management Media Redirection Settings PAM Order Settings SSL Settings SMTP Settings | |
| OS Compatibility | Windows Server 2019 or later Windows Server 2022 or later Red Hat Enterprise Linux 8.6 (x64) or later Red Hat Enterprise Linux 8.7 (x64) or later Red Hat Enterprise Linux 8.8 (x64) or later Red Hat Enterprise Linux 9.0 (x64) or later Red Hat Enterprise Linux 9.1 (x64) or later Red Hat Enterprise Linux 9.2 (x64) or later SUSE Linux Enterprise Server 15 SP4 (x64) or later SUSE Linux Enterprise Server 15 SP5 (x64) or later Ubuntu 20.04.5 LTS (x64) or later Ubuntu 20.04.6 LTS (x64) or later Ubuntu 22.04 LTS (x64) or later Ubuntu 22.04.1 LTS (x64) or later Ubuntu 22.04.2 LTS (x64) or later Ubuntu 22.04.3 LTS (x64) or later VMware ESXi 7.0 Update 3i or later VMware ESXi 8.0 or later VMware ESXi 8.0 Update 1 or later Citrix Hypervisor 8.2 LTSR CU1 or later | |
| System Fans | 4 x 40x40x28mm (25,000rpm) 12 x 60x60x38mm (23,000rpm) | |
| Operating Properties | Operating temperature: 10°C to 35°C Operating humidity: 8%-80% (non-condensing) Non-operating temperature: -40°C to 60°C Non-operating humidity: 20%-95% (non-condensing) | |
| Packaging Dimensions | 1200 x 800 x 444 mm w/ pallet | |
| Packaging Content | 1 x G493-ZB1 2 x CPU fansinks 1 x L-shape Rail kit | |
| Part Numbers | - Barebone package: 6NG493ZB1DR000AAP1* - Motherboard: 9MZB3G41UR-00 - L-shape Rail kit: 25HB2-A96100-K0R - CPU fansink: 25ST0-0Z6023-C1R/25ST0-0Z6024-C1R - Backplane board - CBP10C2: 9CBP10C2NR-00 - Fan module: 25ST2-442829-D0R/25ST2-663823-F1R - PCIe switch board - CPB49A0: 9CPB49A0NR-00 - G-SC Module - CDCG110: 9CDCG110UR-00 - Power supply: 25EP0-230005-G1S | |
| Optional parts | - C19 power cord 125V/15A (US): 25CP1-018000-Q0R - C19 power cord 250V/16A (EU): 25CP3-01830H-Q0R - RMA packaging: 6NG493ZB1SR-RMA-A100 | |
| Order Information | ||
| Manufacturer SKU | G493-ZB1 rev. AAP1 (6NG493ZB1DR000AAP1) | |
| System Building | G493-ZB1 rev. AAP1 (6NG493ZB1DR000AAP1) can be configured individually | |
Gigabyte G493-ZB1-AAP1 Nitelikleri
| Add-on card form factor: | FH, HH |
|---|---|
| Applications: | AI / Deep Learning, AI Inference and Machine Learning, AI inferencing, Application-Optimized Solutions, Big Data, Data Center Optimized, Database, Database Applications, Enterprise Server, GPU server, HPC, High End Enterprise Server, Virtualization, Visual Computing |
| Backplane: | Yes |
| Backplane Interface: | PCIe Gen 5, SAS 1.0, SAS 2.0, SAS 3.0, SAS 4.0, SATA I, SATA II, SATA III, U.2 NVMe |
| Bluetooth Support: | None |
| CPU Codename: | Genoa |
| CPU Manufacturer: | AMD |
| CPU Socket: | LGA 6096 |
| Card Reader Support: | No |
| Certification: | 80 Plus Titanium |
| Chassis Intrusion: | No |
| Computer group: | Server |
| Design: | Rackmount |
| Front I/O: | LED Indicators, USB Type-A |
| GPU quantity per node: | 10 |
| Height units: | 4U |
| HotSwap/Fixed Drives: | Yes |
| HotSwap/Fixed Power Supply: | Hot-Swap Power Supply |
| IPMI / BMC: | Yes |
| Lighting: | LED |
| Motherboard Chipset: | System on Chip |
| Number of CPU sockets: | No |
| Number of RAM Slots: | N/A |
| Onboard Controller: | Intel I350-AM2 |
| Onboard Graphic: | Yes |
| Onboard LAN: | Yes |
| Onboard Network Speed: | 1 Gb/s |
| PSU Power Wattage: | 3000W |
| Performance Class: | Datacenter-Class, Enterprise-Class, High-End |
| Power Supply Cooler: | No |
| Pre-installed Components: | None |
| Pre-installed Software: | Citrix Hypervisor (formerly XenServer), Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu, VMware ESXi, VMware vCenter, Windows Server |
| Product Model: | G493-ZB1-AAP1 |
| Product Version: | Rev-1.x |
| Quantity of Cooler: | 16 |
| Quantity of Power Supplies: | 4 |
| RAID Support: | Yes |
| RAM DIMM Type: | RDIMM |
| RAM ECC: | ECC |
| RAM registered/unregistered: | Registered |
| Redundant power: | Yes |
| Server Fanless: | No |
| Special Features: | LEDs, Suitable for continuous operation |
| Specific Ports: | M.2 Ports, NVMe Ports, SAS Ports, SATA Ports, U.2 Ports, USB Ports, VGA Ports |
| Suitability: | Server |
| Use case: | Database Server, Deep Learning - Machine Learning, GPGPU, High-Performance Computing (HPC), Virtualization, Visual Computing |
| Wi-Fi Support: | None |
| iGPU Manufacturer: | Nvidia |
