R183-Z94-AAV1 | Gigabyte Dual EPYC 9004 EPYC 9005 1U Rack Server

High-Density 1U Dual-Socket AMD EPYC Rack Server Barebone with PCIe Gen5 I/O and the 6NR183Z94DR000ACV1 Gigabyte

The 6NR183Z94DR000ACV1 Gigabyte is a 1U R-Series barebone engineered around dual-socket AMD EPYC 9005/9004 (SP5) to consolidate high core density and high-throughput I/O in space-constrained racks. With up to 192 cores total and a platform tuned for sustained power envelopes, it is well aligned for virtualization clusters, scale-out services, and CPU-driven analytics that require predictable performance under continuous load.

Memory architecture is optimized for bandwidth and capacity with DDR5 RDIMM across 24 DIMM slots, enabling up to 6TB and a 24-channel aggregate design that supports dense VM footprints and in-memory tiers. For expansion, PCIe Gen5 connectivity is designed to keep accelerators and NICs fed, pairing 2x FHHL PCIe Gen5 x16 slots with 2x OCP NIC 3.0 PCIe Gen5 x16 bays for modular high-speed networking. Storage is fronted by 12x 2.5-inch hot-swap bays supporting PCIe Gen5 x4 NVMe or SATA, with SAS-4 enablement via optional HBA/backplane, while 3x internal M.2 slots provide resilient boot options.

Why Choose the 6NR183Z94DR000ACV1 Gigabyte?

The 6NR183Z94DR000ACV1 Gigabyte delivers a practical density-to-performance ratio by combining dual EPYC scalability with PCIe Gen5 expansion and a 12-bay hot-swap storage plane. This architecture supports straightforward growth from compute-heavy consolidation to I/O-bound database tiers, while redundant 80 PLUS Titanium power and out-of-band management help standardize deployment and operations across enterprise racks.

Gigabyte designs the platform with data center serviceability in mind, pairing hot-swap components with an ASPEED AST2600 BMC for IPMI, HTML5 KVM, and remote firmware workflows that align with modern fleet automation and governance requirements.

Key Applications:

• Enterprise virtualization and private cloud
• Hybrid cloud infrastructure nodes
• High-IOPS NVMe and SAS database tiers
• Network services and edge aggregation
• HPC and AI inference I/O expansion

At Happyware Turkiye you benefit from a streamlined procurement path for the 6NR183Z94DR000ACV1 Gigabyte, supported by pre-sales architecture guidance, configuration validation for EPYC, memory, storage, and NIC selections, and dependable enterprise fulfillment for data center rollouts.
