R263-S30-AAH1 | Gigabyte Single Xeon Scalable 4th Gen Xeon Scalable 5th Gen Xeon CPU Max 2U Rack Server
Fiyat sor ↓
Fiyatlar hariç. KDV artı nakliye masrafları
Gigabyte R263-S30-AAH1
Karma NVMe ve SATA/SAS depolama için 6NR263S30DR000AAH1 Gigabyte ile Yüksek Yoğunluklu 2U Tek Soketli Raf Sunucu Barebone
6NR263S30DR000AAH1 Gigabyte, Sapphire Rapids ve Emerald Rapids için tek soketli Intel Xeon Scalable platformu (LGA4677) etrafında tasarlanmış bir 2U raf sunucu barebone’dur. Xeon CPU Max desteği ile düğüm başına güçlü performans sağlarken, lisanslama ve güç yönetimini sadeleştirir. Intel C741 yonga seti, özel bulut, veritabanı ve uç hizmet rolleri için genişleme ve ağ modülerliği adına PCIe Gen5 hatlarını tahsis eden kurumsal bir özellik setini temel alır.
6NR263S30DR000AAH1 Gigabyte’ın bellek alt sistemi, 16 DIMM yuvasıyla 8 kanallı DDR5 ECC RDIMM kullanır ve 4TB’a kadar ölçeklenerek bellek içi veri setlerini ve yüksek eşzamanlılıkta sanallaştırmayı destekler. Depolama tasarımı, gecikme katmanlarıyla kapasiteyi önceliklendirir: 4x NVMe Gen4 ile SATA/SAS karışık arka plan seçeneğine sahip 12 ön sıcak takas yuvası ve buna ek olarak 8x SATA/SAS yuva; SAS çalışması, eklenen HBA/RAID denetleyicisi sayesinde sağlanır. Önyükleme ve hipervizör izolasyonu için dahili bir M.2 PCIe Gen3 x4 NVMe yuvası mevcuttur.
6NR263S30DR000AAH1 Gigabyte'ı Neden Tercih Etmelisiniz?
6NR263S30DR000AAH1 Gigabyte, yüksek TDP’ye sahip tek CPU tasarımını ölçeklenebilir DDR5 kapasitesi, PCIe Gen5 genişlemesi ve servis edilebilir sıcak takas depolaması ile birleştirerek dengeli bir yoğunluk-performans profili sunar. Çift OCP NIC 3.0 SFF yuvası, ağ evrimi için net bir yol sağlar; yedekli 80 PLUS Titanium güç kaynakları ve entegre BMC yönetimi ise raflar arasında güvenilir ve tekrarlanabilir dağıtımları destekler.
Gigabyte, R Serisini veri merkezi servis kolaylığı, doğrulanmış bileşen uyumluluğu ve uzaktan işlemlere pratik bir odakla tasarlar. ASPEED AST2600 ile IPMI ve HTML5 KVM üzerinden platform yönetimi, kurumsal ortamlar için modern tedarik ve yaşam döngüsü kontrol beklentileri ile uyumludur.
Ana Kullanım Alanları:
- Kurumsal sanallaştırma ve özel bulut
- Veritabanları ve uygulama/veri sunumu
- Kapasite-odaklı karma NVMe + SATA/SAS depolama
- Ağ cihazları ve web barındırma
Happyware Türkiye'de, CPU, bellek, depolama ve ağ yol haritanız için 6NR263S30DR000AAH1 Gigabyte boyutlandırmasında deneyimli B2B ön satış rehberliğinden, güvenilir tedarik, yapılandırma desteği ve tutarlı projeler için hızlı proje yönetiminden faydalanırsınız.
Gigabyte R263-S30-AAH1 Teknik Özellikleri
| Single Intel Xeon Scalable 4th Gen CPU, 12x 3.5/2.5" hot-swap drive bays, 2x PCIe (FHHL), 2x OCP 3.0, 1x 1GbE LAN, 2x 1300W Redundant PSUs | ||
| Dimensions (WxHxD, mm) | 2U 438 x 87.5 x 700 |
|
| Motherboard | MS33-DC0 | |
| CPU | 4th Generation Intel® Xeon® Scalable Processors Intel® Xeon® CPU Max Series Intel® Xeon® Platinum Processor, Intel® Xeon® Gold Processor, Intel® Xeon® Silver Processor Single processor, CPU TDP up to 350W |
|
| Socket | 1 x LGA 4677 Socket E |
|
| Chipset | Intel® C741 Chipset | |
| Memory | 16 x DIMM slots DDR5 memory supported only 8-Channel memory architecture RDIMM modules up to 128GB supported 3DS RDIMM modules up to 256GB supported Memory speed: Up to 4800 MHz (1DPC), 4400 MHz (2DPC) |
|
| LAN | Rear side: 1 x 1Gb/s LAN port (1 x Intel® I210-AT) Supports NCSI function 1 x 10/100/1000 management LAN |
|
| Video | Integrated in Aspeed® AST2600 2D Video Graphic Adapter with PCIe bus interface 1920x1200@60Hz 32bpp, DDR4 SDRAM |
|
| Storage | Front side: 4 x 3.5"/2.5" Gen4 NVMe/SATA/SAS hot-swappable bays, from CPU 8 x 3.5"/2.5" SATA/SAS hot-swappable bays SAS card is required for SAS devices support |
|
| SAS | Depends on SAS Add-on card | |
| RAID | Intel® SATA RAID 0/1/10/5 | |
| Expansion Slots | Riser Card CRS201C: - 1 x PCIe x16 (Gen5 x16) FHHL slot, from CPU Riser Card CRS201D: - 1 x PCIe x16 (Gen5 x16) FHHL slot, from CPU 2 x OCP 3.0 slots with PCIe Gen5 x16 bandwidth, from CPU Support NCSI function 1 x M.2 slot: - M-key - PCIe Gen3 x4, from PCH - Supports 2280/22110 cards |
|
| Internal I/O | 1 x M.2 slot 1 x TPM header 1 x VROC connector 2 x OCP 3.0 mezzanine slots |
|
| Front I/O | 2 x USB 3.2 Gen1 1 x Power button with LED 1 x ID button with LED 1 x NMI button 1 x Reset button 1 x LAN activity LED 1 x HDD activity LED 1 x System status LED |
|
| Rear I/O | 2 x USB 3.2 Gen1 1 x Mini-DP 1 x RJ45 1 x MLAN 1 x ID button with LED |
|
| Backplane I/O | Speed and bandwidth: SATA 6Gb/s or SAS 12Gb/s |
|
| TPM | 1 x TPM header with SPI interface Optional TPM2.0 kit: CTM010 |
|
| Power Supply | Dual 1300W (240V) 80 PLUS Titanium redundant power supply AC Input: - 100-127V~/ 12A, 50-60Hz - 200-240V~/ 8A, 50-60Hz DC Input: - 240Vdc/ 7A DC Output: - Max 1000W/ 100-127V~ + 12.2V/ 82A + 12Vsb/ 3A - Max 1300W/ 200-240V~ or 240Vdc Input + 12.2V/ 106A + 12Vsb/ 3A |
|
| System Management | Aspeed® AST2600 management controller GIGABYTE Management Console (AMI MegaRAC SP-X) web interface Dashboard HTML5 KVM Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.) Sensor Reading History Data FRU Information SEL Log in Linear Storage / Circular Storage Policy Hardware Inventory Fan Profile System Firewall Power Consumption Power Control LDAP / AD / RADIUS Support Backup & Restore Configuration Remote BIOS/BMC/CPLD Update Event Log Filter User Management Media Redirection Settings PAM Order Settings SSL Settings SMTP Settings |
|
| OS Compatibility |
Windows Server 2019 |
|
| System Fans | 4 x 80x80x38mm (18,300rpm) | |
| Operating Properties | Operating temperature: 10°C to 35°C Operating humidity: 8%-80% (non-condensing) Non-operating temperature: -40°C to 60°C Non-operating humidity: 20%-95% (non-condensing) |
|
| Packaging Dimensions | 989 x 594 x 279 mm | |
| Packaging Content | 1 x R263-S30 1 x CPU heatsink 1 x Mini-DP to D-Sub cable 3 x Carrier clips 1 x Rail kit |
|
| Part Numbers | - Barebone package: 6NR263S30DR000AAH1* - Motherboard: 9MS33DC0UR-000 - Rail kit: 25HB2-3A0203-K0R - CPU heatsink: 25ST1-323208-A0R - M.2 heatsink: 12SP2-11000E-00R - Front panel board: 9CFP2001NR-00 - Backplane board: 9CBP20C5NR-00 - Fan module: 25ST2-88382T-S1R - Riser card - CRS201C: 9CRS201CNR-00 - Riser card - CRS201D: 9CRS201DNR-00 - Mini-DP to D-Sub cable: 25CRN-200801-K1R - Power supply: 25EP0-21300C-G1S |
|
| Order Information | ||
| Manufacturer SKU | R263-S30 (6NR263S30DR000AAH1) | |
| System Building | R263-S30 (6NR263S30DR000AAH1) can be configured individually | |
Gigabyte R263-S30-AAH1 Nitelikleri
| Anakart Yonga Seti: | Intel C741 |
|---|---|
| Arka panel: | Yes |
| Belirli Bağlantı Noktaları: | USB 3.2 Gen 1 Type-A |
| Bellek ECC Desteği: | ECC |
| Bellek kayıtlı/kayıtsız: | Registered |
| Bluetooth Desteği: | None |
| Dahili Ağ Hızı: | 1 Gbps |
| Dahili Grafik: | Yes |
| Dahili LAN: | 1 |
| Dahili M.2: | x1 M-Key (M.2 22110, M.2 2280) (NVME, PCIe Gen 3) 0 |
| Düğüm başına GPU sayısı: | 0 |
| Düğüm sayısı: | 1 |
| Eklenti kartı form faktörü: | Full-Height Half-Length |
| Eklenti kartı sayısı: | 2 |
| Entegre GPU Üreticisi: | ASpeed |
| Fansız Sunucu: | No |
| Güç Kaynağı Sayısı: | 2 |
| Güç Kaynağı Soğutucu: | No |
| Güç kaynağı Watt Değeri: | 1300W |
| HDD form faktörü: | 2.5", 3.5" |
| HotSwap/Sabit Güç Kaynağı: | Hot-Swap |
| HotSwap/Sabit Sürücüler: | Yes |
| IPMI / BMC Yönetimi: | Yes |
| Kart Okuyucu Desteği: | No |
| Maksimum Bellek: | 4TB |
| Performans Sınıfı: | Enterprise-Class |
| RAID Desteği: | Yes |
| RAM DIMM Türü: | RDIMM |
| Sabit disk yuva sayısı: | 12 |
| Soğutucu Sayısı: | 4 |
| Tasarım: | Rack |
| Uygulamalar: | Application and data serving, Big Data, Cloud Computing, Database, Enterprise, Networking, Virtualization, Web Hosting |
| Uygunluk: | Server |
| Wi-Fi Desteği: | None |
| Yedekli güç kaynağı: | Yes |
| Yükseklik birimleri: | 2U |
| Ön Giriş/Çıkış: | LAN Activity LED, NMI button, Power button with LED, Storage Activity LED, System Reset button, System status LED, UID button with LED, USB |
| Önceden Kurulmuş Bileşenler: | None |
| Önceden Yüklenmiş Yazılım: | Citrix Hypervisor (formerly XenServer), Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu, VMware ESXi, Windows Server |
| Ürün Modeli: | R263-S30-AAH1 |
| İşlemci Kod Adı: | Emerald Rapids, Sapphire Rapids |
| İşlemci Soketi: | E (LGA 4677) |
| İşlemci Türü: | Xeon CPU Max, Xeon Ölçeklenebilir 4. Nesil, Xeon Ölçeklenebilir 5. Nesil |
| İşlemci soket sayısı: | No |
| İşlemci Üreticisi: | Intel |
| Şasi Girişi Algılama: | No |
