Gigabyte R283-Z96-AAE2
Unlock Unrivalled Power with the Gigabyte R283-Z96-AAE2 Barebone System
Introducing the Gigabyte R283-Z96-AAE2 Rack Server, featuring AMD EPYC™ 9005/9004 processors, epitomises high-performance server architecture. Designed to meet the most demanding workloads, it integrates PCIe Gen5 and NVMe storage for superior throughput and energy efficiency. Optimised for future-proof scalability, this server ensures reliable, robust performance for businesses seeking to stay ahead of technological advancements in computing environments.
Why Choose the Gigabyte R283-Z96-AAE2?
The Gigabyte R283-Z96-AAE2 Rack Server delivers impressive processing power with its AMD EPYC™ 9004 processors, capable of handling complex tasks across data centres and AI applications. Featuring support for PCIe Gen5 and high-speed NVMe storage, it enables rapid data processing and maximised bandwidth, making it ideal for demanding workloads.
Designed for scalability and efficiency, the server integrates an advanced thermal management system and energy-efficient components. Its flexibility to scale performance ensures a future-proof infrastructure, enabling seamless upgrades as your enterprise demands grow.
Key Applications:
• Networking
• Hybrid/Private Cloud Server
Transform your infrastructure with the Gigabyte R283-Z96-AAE2 Rack Server. Explore its cutting-edge performance and scalability today. Call us or register as a Happyware partner now for exclusive benefits and support.
Gigabyte R283-Z96-AAE2 Teknik Özellikleri
| Dual AMD EPYC 9005/9004 Series CPU, 24x + 4x 2.5" hot-swap drive bays, 4x PCIe (FHHL), 2x OCP 3.0, 2x 1GbE LAN, 2x 2000W redundant PSUs |
| Dimensions (WxHxD, mm) | 2U 438 x 87.5 x 815 | |
| Motherboard | MZ93-FS1 | |
| CPU | AMD EPYC™ 9005 Series Processors AMD EPYC™ 9004 Series Processors Dual processor, cTDP up to 300W - EPYC 9654 cTDP up to 400W cTDP supported up to 400W under limited thermal conditions. Please contact our sales representatives for more details. If only 1 CPU is installed, some PCIe or memory functions might be unavailable. | |
| Socket | 2 x LGA 6096 Socket SP5 | |
| Chipset | System on Chip | |
| Memory | 24 x DIMM slots DDR5 memory supported 12-Channel memory per processor RDIMM: Up to 4800 MT/s | |
| LAN | Rear (G-SCM board - CDCR114): 2 x 1Gb/s LAN (1 x Intel® I350-AM2) - Support NCSI function 1 x 10/100/1000 Mbps Management LAN | |
| Video | Integrated in Aspeed® AST2600 - 1 x Mini-DP | |
| Storage | Front hot-swap: 4 x 2.5" Gen5 NVMe/SATA/SAS-4 [1] 20 x 2.5" SATA/SAS-4 [1] - (NVMe from CPU_1) Rear hot-swap: 4 x 2.5" SATA/SAS-4 [1] Internal M.2: [1] Storage card is required to enable SATA and SAS drives. | |
| SAS | Supported via storage cards | |
| RAID | Require RAID add-in cards | |
| Expansion Slots | PCIe Cable x 4: - 2 x FHHL x16 (Gen5 x16), from CPU_0 - 2 x FHHL x16 (Gen5 x16), from CPU_1 1 x OCP NIC 3.0 (Gen5 x16), from CPU_0 - Supports NCSI function 1 x OCP NIC 3.0 (Gen5 x16), from CPU_1 - Supports NCSI function | |
| Front I/O | 2 x USB 3.2 Gen1 ports (Type-A) 1 x Power button with LED 1 x ID button with LED 1 x NMI button 1 x Reset button 2 x LAN activity LEDs 1 x Storage activity LED 1 x System status LED | |
| Rear I/O | G-SCM board - CDCR114: 2 x USB 3.2 Gen1 ports (Type-A) 1 x Mini-DP 2 x RJ45 ports 1 x MLAN port 1 x ID LED | |
| Backplane I/O | Speed and bandwidth: Front side - CBP2081: PCIe Gen5 x4 or SATA 6Gb/s or SAS-4 24Gb/s Front side - CBP20G0: PCIe Gen5 x4 or SATA 6Gb/s or SAS-4 24Gb/s Rear side - CBP2025: SATA 6Gb/s or SAS-4 24Gb/s | |
| Security Modules | 1 x TPM header with SPI interface Optional TPM2.0 kit: CTM010 | |
| Power Supply | 1+1 2000W 80 PLUS Platinum redundant power supplies AC Input: - 100-120V~/ 12A, 50/60Hz - 180-240V~/ 10A, 50/60Hz DC Input: (Only for China) - 240Vdc/ 10A DC Output: - Max 1000W/ 100-120V~ +12.2V/ 81.5A +12Vsb/ 2.5A - Max 1600W/ 180-199V~ +12.2V/ 131A +12Vsb/ 2.5A - Max 1800W/ 200-220V~ +12.2V/ 147.5A +12Vsb/ 2.5A - Max 2000W/ 221-240V~ or 240Vdc Input +12.2V/ 163.5A +12Vsb/ 2.5A | |
| System Management | Aspeed® AST2600 management controller GIGABYTE Management Console (AMI MegaRAC SP-X) web interface Dashboard HTML5 KVM Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.) Sensor Reading History Data FRU Information SEL Log in Linear Storage / Circular Storage Policy Hardware Inventory Fan Profile System Firewall Power Consumption Power Control Advanced power capping LDAP / AD / RADIUS Support Backup & Restore Configuration Remote BIOS/BMC/CPLD Update Event Log Filter User Management Media Redirection Settings PAM Order Settings SSL Settings SMTP Settings | |
| OS Compatibility | Windows Server 2019 | |
| System Fans | 4 x 80x80x38mm (18,300rpm) | |
| Operating Properties | Operating temperature: 10°C to 35°C Operating humidity: 8%-80% (non-condensing) Non-operating temperature: -40°C to 60°C Non-operating humidity: 20%-95% (non-condensing) | |
| Packaging Dimensions | 1077 x 679 x 300 mm | |
| Packaging Content | 1 x R283-Z96-AAE2 2 x CPU heatsinks 1 x Mini-DP to D-Sub cable 1 x 2-Section Rail kit | |
| Part Numbers | - Barebone package (EPYC 9005/9004): 6NR283Z96DR000ABE2* - Barebone package (EPYC 9004): 6NR283Z96DR000AAE2* - Motherboard: 9MZ93FS1UR-000* - 2-Section Rail kit (CMA not supported): 25HB2-3A0206-K0R - CPU heatsink: 25ST1-15320G-A0R - M.2 heatsink: 12SP2-11000E-00R - Front panel board - CFP2001: 9CFP2001NR-00* - Backplane board - CBP2025: 9CBP2025NR-00* - Backplane board - CBP2081: 9CBP2081NR-00* - Backplane board - CBP20G0: 9CBP20G0NR-00* - Fan module: 25ST2-88382T-S1R - Expander card - CEP29Q0: 9CEP29Q0NR-00* - G-SCM board - CDCR114: 9CDCR114NR-00* - Mini-DP to D-Sub cable: 25CRN-200801-K1R - Power supply: 25EP0-22000A-L0S | |
| Optional parts | - 3-Section Rail kit (Supports CMA): 25HB2-A56121-K0R - Cable Management Arm: 25HB1-R18300-K0R - RMA packaging: 6NR283Z96SR-RMA-A100 | |
| Order Information | ||
| Manufacturer SKU | R283-Z96-AAE2 (6NR283Z96DR000AAE2) | |
| System Building | R283-Z96-AAE2 (6NR283Z96DR000AAE2) can be configured individually | |
Gigabyte R283-Z96-AAE2 Nitelikleri
| Add-on card form factor: | FH, HH, OCP 3.0 |
|---|---|
| Applications: | Cloud Computing, Enterprise Applications, Enterprise Server, Networking, Virtualization |
| Backplane: | Yes |
| Backplane Interface: | PCIe Gen 5, SAS 1.0, SAS 2.0, SAS 3.0, SAS 4.0, SATA I, SATA II, SATA III, U.2 NVMe |
| Bluetooth Support: | None |
| CPU Codename: | Genoa |
| CPU Manufacturer: | AMD |
| CPU Socket: | LGA 6096 |
| Card Reader Support: | No |
| Certification: | 80 Plus Platinum |
| Chassis Intrusion: | No |
| Computer group: | Server |
| Design: | Rackmount |
| Front I/O: | LED Indicators, USB Type-A |
| Height units: | 2U |
| HotSwap/Fixed Drives: | Yes |
| HotSwap/Fixed Power Supply: | Hot-Swap Power Supply |
| IPMI / BMC: | Yes |
| Lighting: | LED |
| Motherboard Chipset: | System on Chip |
| Number of CPU sockets: | No |
| Number of RAM Slots: | N/A |
| Onboard Controller: | Intel I350-AM2 |
| Onboard Graphic: | No |
| Onboard LAN: | Yes |
| Onboard Network Speed: | 1 Gb/s |
| PSU Power Wattage: | 2000W |
| Performance Class: | Enterprise-Class, Mid-Range |
| Power Supply Cooler: | No |
| Pre-installed Components: | None |
| Pre-installed Software: | Citrix Hypervisor (formerly XenServer), Red Hat Enterprise Linux, Ubuntu, VMware ESXi, Windows Server |
| Product Model: | R283-Z96-AAE2 |
| Product Version: | Rev-1.x |
| Quantity of Cooler: | 4 |
| Quantity of Power Supplies: | 2 |
| RAID Support: | Yes |
| RAM DIMM Type: | RDIMM |
| RAM ECC: | ECC |
| RAM registered/unregistered: | Registered |
| Redundant power: | Yes |
| Server Fanless: | No |
| Special Features: | LEDs, Suitable for continuous operation |
| Specific Ports: | Display Ports, M.2 Ports, NVMe Ports, SAS Ports, SATA Ports, U.2 Ports, USB Ports |
| Suitability: | Server |
| Use case: | Cloud Computing, Networking, Virtualization |
| Wi-Fi Support: | None |
