S452-Z30 | Gigabyte Single EPYC 7002 EPYC 7003 4U Rack Server

High-Density 4U Storage Server Barebone featuring 42-Bay Hybrid Architecture with the 6NS452Z30MR-00 Gigabyte

The 6NS452Z30MR-00 Gigabyte S452-Z30 Rev-A00 is a 4U rack storage server barebone engineered for scale-out capacity nodes that require predictable throughput and serviceability. Built on a single-socket AMD EPYC 7003/7002 SP3 platform, it enables high core density for storage services while maintaining balanced I/O for mixed SAS/SATA and NVMe tiers.

With an 8-channel DDR4 ECC RDIMM/LRDIMM memory architecture and up to 16 DIMM slots, the 6NS452Z30MR-00 Gigabyte supports large in-memory metadata and caching for Ceph/Gluster, virtualization storage, and data lake repositories. PCIe Gen4 expansion provides headroom for modern SAS HBA/RAID adapters and additional networking, while dedicated internal dual M.2 NVMe PCIe Gen3 x4 slots isolate OS boot from the data plane. The 42 hot-swap bays are implemented through a Broadcom SAS35x48 expander backplane, delivering consistent 12Gb/s SAS or 6Gb/s SATA connectivity, with hybrid bays available for NVMe where required.

Why Choose the 6NS452Z30MR-00 Gigabyte?

The 6NS452Z30MR-00 Gigabyte is optimized for density-to-performance ratio in a single 4U footprint, aligning drive-dense deployments with enterprise reliability features such as hot-swap redundancy and out-of-band management. Its scalable I/O profile supports incremental growth: start with SAS/SATA capacity and add PCIe Gen4 accelerators, HBAs, or higher-bandwidth network adapters as cluster requirements expand.

Gigabyte engineers this platform around serviceable storage topology, standards-based management via ASPEED AST2500 BMC with IPMI/HTML5 KVM, and datacentre-aligned power design with hot-swap redundant PSU options. The architecture prioritizes operational continuity, clear separation of boot and data devices, and integration into controlled enterprise change processes.

Key Applications:

• Software-defined storage (Ceph, Gluster)
• Backup and archive repositories
• Data lake and bulk storage
• Virtualization storage nodes
• Scale-out file and object storage

At Happyware Turkiye you benefit from streamlined B2B procurement for the 6NS452Z30MR-00 Gigabyte, with pre-sales configuration guidance, compatibility-focused component selection (HBA/RAID, networking, boot devices), and dependable fulfilment to support planned rollouts and standardized cluster builds.
